2007Harley-Davidson XL1200C Sportster Custom

28 fields on record

The 2007 Harley-Davidson XL1200C Sportster Custom is a lightweight cruiser ideal for riders seeking classic styling with manageable handling. Its air-cooled 1200cc V-twin engine delivers strong low-end torque, while the compact chassis provides excellent maneuverability for urban riding. Known for customization potential and approachable performance, it appeals to both newcomers and experienced riders valuing Harley heritage.

Capacity: 1199.6 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 254.9 kg
Seat height: 711 mm
Power: 74.0 HP (54.4 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (1)

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering35%

City riding55%

Daily riding60%

Touring45%

Two-up40%

Track10%

Best for: Built for relaxed boulevard cruising and custom styling rather than outright speed or cornering performance.
Built for: A classic air-cooled V-twin cruiser with strong low-end torque, laid-back ergonomics, and unmistakable Sportster character.
Not ideal for: Not a good fit for riders seeking sharp cornering agility, high-speed touring comfort, or any off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 711mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2007 Harley-Davidson XL1200C Sportster Custom, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1199.6 ccm
Power: 74.0 HP (54.4 kW)
Torque: 107.3 Nm (10.9 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2903 HP/kg (dry)
Bore x stroke: 88.9 x 96.8 mm
Compression: 9.7:1
Cooling system: Air
Fuel system: Carburettor

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1534 mm
Overall length: 2294 mm
Seat height: 711 mm
Dry weight: 254.9 kg
Wet weight: 267.2 kg
Fuel capacity: 17.00 litres
Ground clearance: 112 mm

Chassis & suspension

Rear suspension: PRICING
Rake (fork angle): 30.1°

Brakes & wheels

Front brakes: Single disc. Dual-piston
Rear brakes: Single disc. Single-piston
Front tyre: 100/90-H19
Rear tyre: 150/80-B16

Other

Color options: Vivid black, black cherry pearl, fire red pearl, deep cobalt pearl, Pacific blue pearl (new), pewter pearl (new), yellow pearl, white gold pearl (new), two-tone olive pearl and vivid black (new), two-tone black cherry pearl and pewter pearl (new), two-ton

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

Safety Recalls

⚠ 1 recall may apply

ELECTRICAL SYSTEM:ALTERNATOR/GENERATOR/REGULATORDec 2006 · 06V476000

ON CERTAIN MOTORCYCLES, AS A RESULT OF A GREATER BODY THICKNESS THAN USED IN PREVIOUS MODEL YEARS, THE VOLTAGE REGULATOR MAY CONTACT THE FRONT FENDER UNDER CERTAIN CONDITIONS. IN SOME CASES THIS CONTACT MAY ALLOW THE FRONT FENDER TO CATCH ON THE TOP SIDE OF THE REGULATOR BODY WHICH COULD IMPEDE THE OPERATOR'S ABILITY TO STEER THE VEHICLE.

Risk: THIS COULD RESULT IN A CRASH WHICH COULD CAUSE INJURY OR DEATH TO THE RIDER.

Remedy: ON MOTORCYCLES WHICH DO NOT HAVE ACCESSORY ENGINE GUARDS, DEALERS WILL INSTALL AN INTERMEDIATE MOUNTING BRACKET THAT WILL RELOCATE THE VOLTAGE REGULATOR TO A POSITION WHICH PROVIDES MORE CLEARANCE FROM THE FRONT FENDER. ON VEHICLES WITH AN ACCESSORY ENGINE GUARDS, DEALERS WILL INSTALL THE THINNNER DIMENSION VOLTAGE REGULATOR TO AVOIDE THE FRONT FENDER CLEARANCE PROBLEM. THE RECALL BEGAN ON JANUARY 22, 2007. A SECOND CUSTOMER LETTER REFLECTING THE ABOVE REMEDY WILL BE SENT TO OWNERS ON MARCH 16, 2007. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

These recalls cover some 2007 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.
