Naked Motorcycles

2018Honda CB1100 EX

Rate this bike

41 fields on record

The 2018 Honda CB1100 EX is a retro-styled middleweight cruiser that appeals to riders seeking classic aesthetics with modern reliability. Known for its air-cooled parallel-twin engine, manageable seat height, and timeless design, it delivers approachable performance and comfortable ergonomics for both experienced and novice riders. Its wire-spoked wheels and vintage styling make it ideal for casual street riding and weekend cruises.

Capacity: 1140.0 ccm
Engine: In-line four, four-stroke
Gearbox: 6-speed
Wet weight: 260.0 kg
Seat height: 795 mm
Power: 88.5 HP (64.6 kW) @ 7500 RPM

⇄ Compare with another bike All model years

Other years 2015 2016 2017 2018 2019

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail10%

Cornering60%

City riding65%

Daily riding75%

Touring68%

Two-up70%

Track25%

Best for: Built for relaxed retro-styled riding, weekend cruising, and enjoying the character of a traditional air-cooled inline-four rather than chasing lap times.
Built for: Delivers smooth, linear power with a classic UJM soundtrack and feel, prioritizing rideability and nostalgia over aggression.
Not ideal for: Not the right choice for riders wanting sharp sportbike handling, off-road capability, or class-leading acceleration.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 795mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2018 Honda CB1100 EX, with a relaxed knee angle of around 125 degrees and a forward-leaning riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1140.0 ccm
Power: 88.5 HP (64.6 kW) @ 7500 RPM
CO2 Emissions: 139 CO2 g/km
Torque: 91.0 Nm (9.3 kgf-m) @ 5000 RPM
Engine type: In-line four, four-stroke
Fuel consumption: 6.00 litres/100 km (16.7 km/l)
Power/weight ratio: 0.3404 HP/kg (wet)
Bore x stroke: 73.5 x 67.2 mm
Compression: 9.5:1
Cooling system: Oil & air
Fuel system: Injection
Starting: Electric
Ignition: Digital transistorized with electronic advance

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Multi-plate wet clutch

Dimensions & weight

Wheelbase: 1490 mm
Overall length: 2195 mm
Overall width: 834 mm
Overall height: 1130 mm
Seat height: 795 mm
Wet weight: 260.0 kg
Fuel capacity: 17.50 litres
Ground clearance: 135 mm
Oil capacity: 4.90 litres
Dry weight: Not on record - add it

Chassis & suspension

Frame: Double steel cradle
Front suspension: 41mm conventional fork with adjustable spring preload
Rear suspension: Twin shocks with adjustable spring preload
Rake (fork angle): 27.0°
Trail: 114 mm

Brakes & wheels

Front brakes: Double disc. Floating discs. Four-piston calipers. ABS.
Front brakes diameter: 296 mm
Rear brakes: Single disc. Single-piston. ABS.
Rear brakes diameter: 256 mm
ABS: Yes
Front tyre: 110/80-R18
Rear tyre: 140/70-R18

Other

Color options: Candy Red
Comments: Model ID: CB1100CAH

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2015	2016	2017	2018	2019
Capacity	1140 cc	1140 cc	1140 cc	1140 cc	1140 cc
Seat height	795 mm	795 mm	795 mm	795 mm	792 mm
Fuel capacity	17.5 L	17.5 L	17.5 L	17.5 L	16.8 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Rider Reviews

—

☆☆☆☆☆

Be the first to rate

MotorcycleDB Review

The 2018 Honda CB1100 EX is a modern classic motorcycle with a timeless design that pays homage to Honda's rich history in the two-wheeled world. This bike features a powerful 1140cc air-cooled inline four-cylinder engine that delivers smooth and responsive performance on the open road. The CB1100 EX also comes equipped with modern amenities such as ABS brakes, LED lighting, and a digital instrument cluster, making it a great choice for riders who appreciate classic styling with contemporary technology.

With its comfortable riding position and well-balanced chassis, the 2018 Honda CB1100 EX offers a smooth and refined ride that is perfect for long-distance cruising. The bike's retro styling, combined with its modern features, makes it a standout choice in the modern classic motorcycle category. Whether you're a seasoned rider or new to the world of motorcycles, the CB1100 EX is a reliable and stylish choice that is sure to turn heads on the road.
