Honda CB1100 EX - 2018 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryClassic
Year2018
ModelHonda CB1100 EX



Engine and Transmission Specifications

Greenhouse gases139.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption6.00 litres/100 km (16.7 km/l or 39.20 mpg)
ClutchMulti-plate wet clutch
Transmission type,final driveChain
Gearbox6-speed
Cooling systemOil & air
IgnitionDigital transistorized with electronic advance
Fuel controlDouble Overhead Cams/Twin Cam (DOHC)
Fuel systemInjection. PGM-FI electronic fuel injection
Bore x Stroke73.5 x 67.2 mm (2.9 x 2.6 inches)
Compression9.5:1
Torque91.00 Nm (9.3 kgf-m or 67.1 ft.lbs) @ 5000 Revolutions">RPM
Power88.51 Horsepower">HP (64.6 Kilowatt">kW)) @ 7500 Revolutions">RPM
Engine typeIn-line four, four-stroke

Brakes, suspension, Frame and wheels

WheelsWire spoked
Rear brakes diameter256 mm (10.1 inches)
Rear brakesSingle disc. Single-piston. ABS.
Front brakes diameter296 mm (11.7 inches)
Front brakesDouble disc. Floating discs. Four-piston calipers. ABS.
Rear tyre140/70-R18
Front tyre110/80-R18
Rear SuspensionTwin shocks with adjustable spring preload
Front Suspension41mm conventional fork with adjustable spring preload
Trail114 mm (4.5 inches)
Rake (fork angle)27.0°
Frame typeDouble steel cradle



Physical measures and capacities

Oil capacity4.90 litres (0.32 quarts)
Fuel capacity17.50 litres (4.62 gallons)
Wheelbase1,490 mm (58.7 inches)
Ground clearance135 mm (5.3 inches)
Overall width834 mm (32.8 inches)
Overall length2,195 mm (86.4 inches)
Overall height1,130 mm (44.5 inches)
Seat height795 mm (31.3 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc260.0 kg (573.2 pounds)

Other specs

CommentsModel ID: CB1100CAH
Electrical11.2Ah battery.
InstrumentsFuel gauge, instant fuel consumption, remaining range, clock, new gear position indicator
StarterElectric
Color optionsCandy Red

Rider Reviews

Total comments: 1
64x64

MotorcycleDB Review

The 2018 Honda CB1100 EX is a modern classic motorcycle with a timeless design that pays homage to Honda's rich history in the two-wheeled world. This bike features a powerful 1140cc air-cooled inline four-cylinder engine that delivers smooth and responsive performance on the open road. The CB1100 EX also comes equipped with modern amenities such as ABS brakes, LED lighting, and a digital instrument cluster, making it a great choice for riders who appreciate classic styling with contemporary technology. With its comfortable riding position and well-balanced chassis, the 2018 Honda CB1100 EX offers a smooth and refined ride that is perfect for long-distance cruising. The bike's retro styling, combined with its modern features, makes it a standout choice in the modern classic motorcycle category. Whether you're a seasoned rider or new to the world of motorcycles, the CB1100 EX is a reliable and stylish choice that is sure to turn heads on the road.
