Honda CTX1300 - 2014 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2014
Model:Honda CTX1300

Engine and Transmission Specifications

Emission details:Meets current EPA standards. Models sold in California meet current CARB standards and may differ slightly due to emissions equipment.
Transmission type,final drive:Shaft drive (cardan)
Gearbox:5-speed
Cooling system:Liquid
Ignition:Computer-controlled digital with 3-D mapping and electronic advance
Fuel control:DOHC
Fuel system:Injection. PGM-FI with electronic control IACV, four 36mm throttle bodies
Valves per cylinder:4
Bore x stroke:78.0 x 66.0 mm (3.1 x 2.6 inches)
Compression:10.0:1
Engine type:V4, four-stroke
Capacity:1261.00 ccm (76.95 cubic inches)

Brakes, suspension, Frame and wheels

Rear brakes diameter:315 mm (12.4 inches)
Rear brakes:Single disc
Front brakes diameter:310 mm (12.2 inches)
Front brakes:Double disc
Rear tyre dimensions:200/50-R17
Front tyre dimensions:130/70-R18
Rear suspension travel:110 mm (4.3 inches)
Rear suspension:Twin rear shocks with spring
Front suspension travel:107 mm (4.2 inches)
Front suspension:Inverted 45mm fork
Trail:114 mm (4.5 inches)
Rake (fork angle):28.5°


Physical measures and capacities

Fuel capacity:12.40 litres (3.28 gallons)
Wheelbase:1,530 mm (60.2 inches)
Ground clearance:130 mm (5.1 inches)
Overall width:855 mm (33.7 inches)
Overall length:2,255 mm (88.8 inches)
Overall height:1,155 mm (45.5 inches)
Seat height:720 mm (28.3 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:328.5 kg (724.2 pounds)


Other specs

Carrying capacity:Saddle bags, top box
Wheelbase:1,595 mm (62.8 inches)
Rear tyre:150/70-R17
Front tyre:110/80-R19
Rear Suspension:Pro-Link with gas-charged damper, preload and stepless rebound damping adjustment
Front Suspension:43mm inverted telescopic forks with hydraulic damping, preload and rebound damping adjustment
Frame type:Diamond; aluminium twin-spar
Greenhouse gases:142.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption:6.13 litres/100 km (16.3 km/l or 38.37 mpg)
Driveline:Enclosed shaft
Clutch:DCT = D mode/S mode/Manual mode
Bore x Stroke:81.0 x 60.0 mm (3.2 x 2.4 inches)
Compression:12.0:1
Torque:126.00 Nm (12.8 kgf-m or 92.9 ft.lbs) @ 6500 Revolutions">RPM
Power:127.40 Horsepower">HP (93.0 Kilowatt">kW)) @ 7750 Revolutions">RPM
Engine details:76 degree cyclinder angle
Capacity:1237.00 ccm (75.48 cubic inches)
Model:Honda Crosstourer Highlander
Comments:Model ID: CTX1300
Color options:Metallic Black, Gray Blue Metallic, Candy Red
Factory warranty:24 months
Starter:Electric
