Honda NX 650 Dominator - 2002 Specifications and Reviews

5 stars Average rating: 5 from 1 votes
.

General information

Category:Enduro / offroad
Year:2002
Model:Honda NX 650 Dominator


Engine and Transmission Specifications

Transmission typefinal drive:Chain
Gearbox:5-speed
Fuel system:Carburettor
Bore x stroke:100.0 x 82.0 mm (3.9 x 3.2 inches)
Compression:8.3:1
Torque:51.00
Power:41.80
Stroke:4
Engine type:Single cylinder
Capacity:644.00 ccm (39.30 cubic inches)

Physical measures and capacities

Wheelbase:1,450 mm (57.1 inches)
Ground clearance:250 mm (9.8 inches)
Overall width:910 mm (35.8 inches)
Overall length:2,200 mm (86.6 inches)
Overall height:1,260 mm (49.6 inches)
Seat height:880 mm (34.6 inches) If adjustable, lowest setting.
Dry weight:167.0 kg (368.2 pounds)

Honda NX 650 Dominator dimensions and frame

Rear brakes diameter:220 mm (8.7 inches)
Rear brakes:Single disc
Front brakes diameter:256 mm (10.1 inches)
Front brakes:Single disc
Rear tyre dimensions:120/90-17 64S
Front tyre dimensions:90/90-21 54S
Rear suspension travel:195 mm (7.7 inches)
Front suspension travel:220 mm (8.7 inches)

Speed and acceleration

Power/weight ratio:0.2503 HP/kg

Other specs

Fuel capacity:16.00 litres (4.23 gallons)
