Category: | Custom / cruiser |
Year: | 2012 |
Model: | Honda Sabre |
|
Engine and Transmission Specifications |
Emission details: | Meets current EPA standards. California version meets current California Air Resources Board (CARB) standards and may differ slightly due to emissions equipment. |
Transmission type,final drive: | Shaft drive (cardan) |
Gearbox: | 5-speed |
Cooling system: | Liquid |
Ignition: | Digital with 3-D mapping, two spark plugs per cylinder |
Fuel control: | SOHC |
Fuel system: | Injection. PGM-FI with automatic enrichment circuit, one 38mm throttle body |
Valves per cylinder: | 3 |
Bore x stroke: | 89.5 x 104.3 mm (3.5 x 4.1 inches) |
Compression: | 9.2:1 |
Engine details: | 52 degree V-twin |
Engine type: | V2, four-stroke |
Capacity: | 1312.00 ccm (80.06 cubic inches) |
Brakes, suspension, Frame and wheels |
Rear brakes diameter: | 296 mm (11.7 inches) |
Rear brakes: | Single disc. Twin-piston caliper |
Front brakes diameter: | 336 mm (13.2 inches) |
Front brakes: | Double disc. Twin-piston caliper |
Rear tyre dimensions: | 170/80-15 |
Front tyre dimensions: | 90/90-21 |
Rear suspension travel: | 99 mm (3.9 inches) |
Rear suspension: | Single shock |
Front suspension travel: | 102 mm (4.0 inches) |
Front suspension: | 41mm fork |
Trail: | 115 mm (4.5 inches) |
Rake (fork angle): | 33.0° |
|
Physical measures and capacities |
Fuel capacity: | 16.65 litres (4.40 gallons) |
Wheelbase: | 1,786 mm (70.3 inches) |
Seat height: | 683 mm (26.9 inches) If adjustable, lowest setting. |
Weight incl. oil, gas, etc: | 301.2 kg (664.0 pounds) |
Other specs |
Comments: | Model ID: TRX680FA |
Reserve fuel capacity: | 4.54 litres (1.20 gallons) |
Wheelbase: | 1,290 mm (50.8 inches) |
Ground clearance: | 254 mm (10.0 inches) |
Overall width: | 1,189 mm (46.8 inches) |
Overall length: | 2,113 mm (83.2 inches) |
Overall height: | 1,207 mm (47.5 inches) |
Rear tyre: | 25/10-12 |
Front tyre: | 25/8-12 |
Rear wheel travel: | 203 mm (8.0 inches) |
Rear Suspension: | Independent double-wishbone |
Front wheel travel: | 175 mm (6.9 inches) |
Front Suspension: | Independent double-wishbone |
Driveline: | Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential |
Clutch: | Automatic |
Lubrication system: | Dry sump |
Bore x Stroke: | 102.0 x 82.6 mm (4.0 x 3.3 inches) |
Compression: | 12.0:1 |
Model: | Honda FourTrax Rincon |
Color options: | Ultra Blue Metallic |
Factory warranty: | One Year. Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan. |
Starter: | Electric |
