Honda VT1300CS - 2013 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes

General information

Category:Custom / cruiser
Model:Honda VT1300CS

Engine and Transmission Specifications

Greenhouse gases:114.4 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption:4.93 litres/100 km (20.3 km/l or 47.71 mpg)
Transmission type,final drive:Shaft drive (cardan)
Cooling system:Liquid
Ignition:Digital with 3-dimensional mapping, 2 sparks per cylinder
Fuel control:Single Overhead Cams (SOHC)
Fuel system:Injection. PGM-FI with automatic enricher circuit
Valves per cylinder:4
Bore x Stroke:89.5 x 104.3 mm (3.5 x 4.1 inches)
Torque:107.00 Nm (10.9 kgf-m or 78.9 ft.lbs) @ 2250 Revolutions">RPM
Power:56.99 Horsepower">HP (41.6 Kilowatt">kW)) @ 4250 Revolutions">RPM
Engine details:52° V-twin
Engine type:V2, four-stroke
Capacity:1312.00 ccm (80.06 cubic inches)

Brakes, suspension, Frame and wheels

Wheels:Cast aluminium
Rear brakes diameter:296 mm (11.7 inches)
Rear brakes:Single disc. ABS
Front brakes diameter:336 mm (13.2 inches)
Front brakes:Double disc. ABS. Twin-piston caliper
Rear tyre:200/50-18
Front tyre:90/90-21
Rear Suspension:Monoshock with adjustable rebound damping and 35-position spring preload adjustability, 95mm axle travel
Front Suspension:45mm telescopic fork with 130mm stroke and 102.4mm axle travel

Physical measures and capacities

Fuel capacity:20.30 litres (5.36 gallons)
Wheelbase:1,805 mm (71.1 inches)
Ground clearance:126 mm (5.0 inches)
Overall width:900 mm (35.4 inches)
Overall length:2,575 mm (101.4 inches)
Overall height:1,150 mm (45.3 inches)
Seat height:678 mm (26.7 inches) If adjustable, lowest setting.
Power/weight ratio:0.1844 HP/kg
Dry weight:309.0 kg (681.2 pounds)

Other specs

Comments:Sold in Australia.
Color options:Orange, silver
