Indian Springfield Dark Horse - 2018 Specifications and Reviews

5 stars Average rating: 5 from 1 votes

General information

Model:Indian Springfield Dark Horse

Engine and Transmission Specifications

Exhaust system:Split dual exhaust with cross-over
Clutch:Wet multi-plate
Transmission type,final drive:Belt
Cooling system:Air
Fuel system:Injection. Closed Loop Sequential Port Fuel Injection
Bore x Stroke:101.0 x 113.0 mm (4.0 x 4.4 inches)
Torque:150.00 Nm (15.3 kgf-m or 110.6 ft.lbs) @ 2100 Revolutions">RPM
Engine details:Thunder Stroke® 111 engine, blacked out
Engine type:V2, four-stroke
Capacity:1811.00 ccm (110.51 cubic inches)

Brakes, suspension, Frame and wheels

Seat:Dual leather seat
Wheels:Cast aluminium wheels
Rear brakes diameter:300 mm (11.8 inches)
Rear brakes:Single disc. ABS. Floating disc. 2-piston caliper.
Front brakes diameter:300 mm (11.8 inches)
Front brakes:Double disc. ABS. Floating discs. 4 piston caliper.
Rear tyre:180/60-B16
Front tyre:130/90-B16
Rear wheel travel:114 mm (4.5 inches)
Rear Suspension:Single shock
Front wheel travel:119 mm (4.7 inches)
Front Suspension:Telescopic forks with air adjust
Trail:133 mm (5.2 inches)
Rake (fork angle):25.0°
Frame type:Cast Aluminum Frame with Integrated Air-Box

Physical measures and capacities

Fuel capacity:20.80 litres (5.50 gallons)
Wheelbase:1,701 mm (67.0 inches)
Ground clearance:142 mm (5.6 inches)
Overall width:990 mm (39.0 inches)
Overall length:2,583 mm (101.7 inches)
Overall height:1,442 mm (56.8 inches)
Seat height:660 mm (26.0 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:388.0 kg (855.4 pounds)
Dry weight:372.0 kg (820.1 pounds)

Other specs

Comments:Windscreen. Cruise Control.
Factory warranty:2 years
Carrying capacity:Hard saddle bags.
Light:Tear drop head lamp, spot lights, fender light
Instruments:Tank Mounted Electronic Speedometer with Odometer; Dual Tripmeters; Digital Tachometer; Ambient Air Temperature; Fuel Range; Average Fuel Economy; Battery Voltage; Gear Position Display;
Color options:Thunder Black Smoke
