Indian Springfield Dark Horse - 2018 Specifications and Reviews
2018
General information | |
| Category: | Touring |
| Year: | 2018 |
| Model: | Indian Springfield Dark Horse |
Engine and Transmission Specifications | |
| Exhaust system: | Split dual exhaust with cross-over |
| Clutch: | Wet multi-plate |
| Transmission type,final drive: | Belt |
| Gearbox: | 6-speed |
| Cooling system: | Air |
| Fuel system: | Injection. Closed Loop Sequential Port Fuel Injection |
| Bore x Stroke: | 101.0 x 113.0 mm (4.0 x 4.4 inches) |
| Compression: | 9.5:1 |
| Torque: | 150.00 Nm (15.3 kgf-m or 110.6 ft.lbs) @ 2100 Revolutions">RPM |
| Engine details: | Thunder Stroke® 111 engine, blacked out |
| Engine type: | V2, four-stroke |
| Capacity: | 1811.00 ccm (110.51 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Seat: | Dual leather seat |
| Wheels: | Cast aluminium wheels |
| Rear brakes diameter: | 300 mm (11.8 inches) |
| Rear brakes: | Single disc. ABS. Floating disc. 2-piston caliper. |
| Front brakes diameter: | 300 mm (11.8 inches) |
| Front brakes: | Double disc. ABS. Floating discs. 4 piston caliper. |
| Rear tyre: | 180/60-B16 |
| Front tyre: | 130/90-B16 |
| Rear wheel travel: | 114 mm (4.5 inches) |
| Rear Suspension: | Single shock |
| Front wheel travel: | 119 mm (4.7 inches) |
| Front Suspension: | Telescopic forks with air adjust |
| Trail: | 133 mm (5.2 inches) |
| Rake (fork angle): | 25.0° |
| Frame type: | Cast Aluminum Frame with Integrated Air-Box |
Physical measures and capacities | |
| Fuel capacity: | 20.80 litres (5.50 gallons) |
| Wheelbase: | 1,701 mm (67.0 inches) |
| Ground clearance: | 142 mm (5.6 inches) |
| Overall width: | 990 mm (39.0 inches) |
| Overall length: | 2,583 mm (101.7 inches) |
| Overall height: | 1,442 mm (56.8 inches) |
| Seat height: | 660 mm (26.0 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc: | 388.0 kg (855.4 pounds) |
| Dry weight: | 372.0 kg (820.1 pounds) |
Other specs | |
| Comments: | Windscreen. Cruise Control. |
| Factory warranty: | 2 years |
| Carrying capacity: | Hard saddle bags. |
| Light: | Tear drop head lamp, spot lights, fender light |
| Instruments: | Tank Mounted Electronic Speedometer with Odometer; Dual Tripmeters; Digital Tachometer; Ambient Air Temperature; Fuel Range; Average Fuel Economy; Battery Voltage; Gear Position Display; |
| Starter: | Electric |
| Color options: | Thunder Black Smoke |
