Cruisers

2020Indian Springfield Dark Horse

Rate this bike

47 fields on record

The 2020 Indian Springfield Dark Horse is a cruiser motorcycle designed for riders seeking classic styling with modern technology and comfort. Known for its retro aesthetics, low seat height, and comprehensive digital instrumentation, it delivers a balanced riding experience suited to both highway cruising and city navigation. Its manageable weight and dimensions make it accessible to a broad range of riders while maintaining the commanding presence characteristic of the Dark Horse nameplate.

Capacity: 1811.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 349.0 kg
Seat height: 660 mm
Power: 92.0 HP (67.7 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (3)

What’s new for the 2020 Indian Springfield Dark Horse

vs the 2019

Spec	2019	2020
Compression	9.5:1	11.1:1

Other years 2018 2019 2020 2021 2022 2023 2024 2025 2026

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail10%

Cornering35%

City riding40%

Daily riding55%

Touring88%

Two-up80%

Track10%

Best for: Built for relaxed highway cruising and long-distance touring rather than sport riding or commuting agility.
Built for: A big-twin American cruiser that rewards a laid-back riding style with strong low-end torque, deep exhaust note, and classic touring presence.
Not ideal for: Not the right choice for riders wanting a nimble, lightweight bike for quick city commuting or off-road adventure.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 660mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2020 Indian Springfield Dark Horse, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1811.0 ccm
Power: 92.0 HP (67.7 kW)
CO2 Emissions: 146 CO2 g/km
EPA Est. Fuel Consumption: 6.22 L/100km (1463.0 US mpg)
EPA CO Emissions: 3.2 CO g/km
Torque: 161.4 Nm (16.5 kgf-m) @ 3000 RPM
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2636 HP/kg
Bore x stroke: 103.0 x 113.0 mm
Compression: 11.1:1
Cooling system: Air
Fuel system: Injection
Starting: Electric
Aspiration: Naturally aspirated
Valves per cylinder: 2

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: Wet multi-plate

Dimensions & weight

Wheelbase: 1701 mm
Overall length: 2522 mm
Overall width: 1000 mm
Overall height: 1176 mm
Seat height: 660 mm
Dry weight: 349.0 kg
Wet weight: 360.0 kg
Fuel capacity: 20.80 litres
Ground clearance: 133 mm
Carrying capacity: Hard saddle bags.

Chassis & suspension

Frame: Cast Aluminum Frame with Integrated Air-Box
Front suspension: Telescopic forks with air adjust
Rear suspension: Single shock
Front wheel travel: 119 mm
Rear wheel travel: 114 mm
Rake (fork angle): 25.0°
Trail: 133 mm

Brakes & wheels

Front brakes: Double disc. ABS. Floating discs. 4 piston caliper.
Front brakes diameter: 300 mm
Rear brakes: Single disc. ABS. Floating disc. 2-piston caliper.
Rear brakes diameter: 300 mm
ABS: Yes
Front tyre: 130/90-B16
Rear tyre: 180/60-B16

Other

Color options: Thunder Black Smoke, Sagebrush Smoke, White Smoke
Warranty: 24
Fuel Tank Material: M

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2018	2020	2022	2024	2026
Capacity	1811 cc	1811 cc	1890 cc	1890 cc	1890 cc
Dry weight	372 kg	349 kg	344 kg	344 kg	344 kg
Seat height	660 mm	660 mm	650 mm	650 mm	650 mm
Fuel capacity	20.8 L	20.8 L	20.8 L	20.8 L	20.8 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 3 open recalls

FUEL SYSTEM, GASOLINE:DELIVERY:FUEL PUMPFeb 2025 · 25V108000

Indian Motorcycle Company (Indian) is recalling certain 2025 Challenger Dark Horse, Pursuit Limited, Roadmaster Elite and Springfield Dark Horse motorcycles. Due to an incorrectly crimped wire, the fuel pump may fail and result in an engine stall during operation.

Risk: An engine stall increases the risk of a crash or injury.

Remedy: Dealers will replace the fuel pump, free of charge. Owner notification letters were mailed March 5, 2025. Owners may contact Indian customer service at 877-204-3697. Indian's number for this recall is I-25-01.

SUSPENSION:REARJul 2024 · 24V550000

Indian Motorcycle Company (Indian) is recalling certain 2024 Chieftain, Challenger, Pursuit, Roadmaster, and Springfield motorcycles. Please refer to the recall report for a complete list of model names. The rear suspension pushrod may buckle under load.

Risk: A rear suspension pushrod that buckles may pinch the main chassis harness, damage the coolant reservoir, damage the rear tire, or cause the motorcycle to bottom out under load. Any of these scenarios can increase the risk of a crash or injury.

Remedy: Dealers will replace the rear suspension pushrod, free of charge. Owner notification letters were mailed August 22, 2024. Owners may contact Indian customer service at 1-877-204-3697. Indian's number for this recall is I-24-07.

ENGINE AND ENGINE COOLING:ENGINE:CRANK/CAMSHAFT POSITION SENSORDec 2023 · 23V829000

Indian Motorcycle Company (Indian) is recalling certain 2023 Chieftain Elite, 2023-2024 Chieftain Dark Horse, Chieftain Dark Horse Icon, Chieftain Limited, Chieftain, Roadmaster Limited, Roadmaster Dark Horse, Roadmaster, Springfield, Springfield Dark Horse, and 2024 Roadmaster Elite motorcycles. The crankshaft position sensor may have been routed improperly, which can result in an engine stall.

Risk: An engine stall can increase the risk of a crash or injury.

Remedy: Dealers will inspect and reroute, or replace the crankshaft position sensor as necessary, free of charge. Owner notification letters were mailed December 22, 2023. Owners may contact Indian customer service at 1-877-204-3697. Indian's number for this recall is I-23-07.

Source: NHTSA. View all Indian recalls →

Rider Reviews

—

☆☆☆☆☆

Be the first to rate

MotorcycleDB Review

The 2020 Indian Springfield Dark Horse motorcycle is a stunningly sleek and powerful cruiser bike that is sure to turn heads on the road. With its matte black finish and aggressive styling, this bike exudes an air of confidence and ruggedness. The Thunder Stroke 116 V-Twin engine provides impressive power and torque, while the comfortable riding position and smooth suspension make for an enjoyable and easy ride. Whether you're cruising the open highway or navigating city streets, the Indian Springfield Dark Horse offers an exhilarating experience for riders looking for both style and performance.

From its impressive performance capabilities to its eye-catching design, the 2020 Indian Springfield Dark Horse is an exceptional choice for motorcycle enthusiasts. The bike's powerful Thunder Stroke 116 engine delivers plenty of torque for exhilarating acceleration, while the comfortable seating and smooth suspension make for a pleasant ride. With its striking matte black finish and aggressive styling, the Dark Horse stands out from the crowd and is sure to make a bold statement on the road. Overall, the 2020 Indian Springfield Dark Horse is a top-of-the-line cruiser motorcycle that offers both power and style in a single, impressive package.
