KTM 1290 Super Adventure S - 2017 Specifications and Reviews

2017
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Allround
Year:2017
Model:KTM 1290 Super Adventure S

Engine and Transmission Specifications

Driveline:5/8  x  5/16 X Ring. Primary drive: 40:76.
Clutch:PASC slipper clutch, hydraulically actuated
Transmission type,final drive:Chain
Gearbox:6-speed
Cooling system:Liquid
Lubrication system:Forced oil lubrication with 3 pumps
Ignition:Keihin EMS with RBW and cruise control, double ignition
Fuel system:Injection
Bore x Stroke:108.0 x 75.0 mm (4.3 x 3.0 inches)
Torque:140.00 Nm (14.3 kgf-m or 103.3 ft.lbs)
Power:160.00 Horsepower">HP (116.8 Kilowatt">kW))
Engine details:75° V arrangement
Engine type:V2, four-stroke
Capacity:1301.00 ccm (79.39 cubic inches)


Brakes, suspension, Frame and wheels

Rear brakes diameter:267 mm (10.5 inches)
Rear brakes:Single disc. ABS. Two-piston calipers.
Front brakes diameter:320 mm (12.6 inches)
Front brakes:Double disc. ABS. Four-piston calipers. Radially mounted.
Rear wheel travel:200 mm (7.9 inches)
Rear Suspension:WP Semi-active suspension monoshock
Front wheel travel:200 mm (7.9 inches)
Front Suspension:WP Semi-active suspension USD Ø 48 mm
Rake (fork angle):26.0°
Frame type:Chromium-Molybdenum steel trellis frame, powder coated

Physical measures and capacities

Fuel capacity:23.00 litres (6.08 gallons)
Wheelbase:1,580 mm (62.2 inches)
Ground clearance:220 mm (8.7 inches)
Seat height:860 mm (33.9 inches) If adjustable, lowest setting.
Power/weight ratio:0.7442 HP/kg
Dry weight:215.0 kg (474.0 pounds)

Other specs

Comments:Small windscreen. Ride-by-wire system. Bosch cornering ABS and offroad mode, disengageable.
Instruments:6.5” TFT display
Starter:Electric
Color options:White/orange/black
