KTM 65 SX - 2018 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes

General information

Category:Cross / motocross
Model:KTM 65 SX

Engine and Transmission Specifications

Driveline:14:48. Primary drive: 23:75 straight cut spur gear.
Clutch:Wet, multi-disc clutch, Formula hydraulics
Transmission type,final drive:Chain
Cooling system:Liquid
Lubrication system:Mixture oil lubrication
Ignition:AET digital EMS
Fuel system:Carburettor. Mikuni TMX
Bore x Stroke:45.0 x 40.8 mm (1.8 x 1.6 inches)
Engine details:Reed intake
Engine type:Single cylinder, two-stroke
Capacity:64.85 ccm (3.96 cubic inches)

Brakes, suspension, Frame and wheels

Wheels:Black anodized, aluminum rims
Rear brakes diameter:160 mm (6.3 inches)
Rear brakes:Single disc. Two-piston calipers. Wave brake discs.
Front brakes diameter:198 mm (7.8 inches)
Front brakes:Single disc. Four-piston calipers. Wave brake discs.
Rear wheel travel:270 mm (10.6 inches)
Rear Suspension:WP shock absorber
Front wheel travel:215 mm (8.5 inches)
Front Suspension:WP upside-down Ø 35 mm
Rake (fork angle):25.5°
Frame type:Central-tube frame with double-cradle

Physical measures and capacities

Fuel capacity:3.50 litres (0.92 gallons)
Wheelbase:1,137 mm (44.8 inches)
Ground clearance:280 mm (11.0 inches)
Seat height:750 mm (29.5 inches) If adjustable, lowest setting.
Dry weight:53.0 kg (116.8 pounds)

Other specs

Color options:Orange/white/black
