KTM 990 Super Duke R - 2009 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryNaked bike
Year2009
ModelKTM 990 Super Duke R

Engine and Transmission Specifications

Exhaust systemStainless steel silencer with regulated catalytic converter
ClutchWet multi-disc clutch, operated hydraulically
Transmission type,final driveChain
Gearbox6-speed
Cooling systemLiquid
Lubrication systemPressure lubrication
Fuel controlDOHC
Fuel systemInjection. Keihin
Valves per cylinder4
Bore x stroke101.0 x 62.4 mm (4.0 x 2.5 inches)
Compression11.5:1
Torque102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 7000
Power130.07
Engine typeV2, four-stroke
Capacity:999.00 ccm (60.96 cubic inches)



Brakes, suspension, Frame and wheels

Rear brakes diameter240 mm (9.4 inches)
Rear brakesSingle disc. Brembo single-piston floating caliper
Front brakes diameter320 mm (12.6 inches)
Front brakesDouble disc. 2 x Brembo four piston, radially bolted caliper
Rear tyre dimensions180/55-ZR17
Front tyre dimensions120/70-ZR17
Rear suspension travel160 mm (6.3 inches)
Rear suspensionWP monoshock
Front suspension travel135 mm (5.3 inches)
Front suspensionWP USD
Rake (fork angle)22.7°
Frame typeChromium-Molybdenum trellis frame, powder coated. Aluminium 7020 subframe.

Physical measures and capacities

Reserve fuel capacity2.50 litres (0.66 gallons)
Fuel capacity18.50 litres (4.89 gallons)
Wheelbase1,450 mm (57.1 inches)
Ground clearance150 mm (5.9 inches)
Seat height855 mm (33.7 inches) If adjustable, lowest setting.
Power/weight ratio0.6993 HP/kg
Dry weight186.0 kg (410.1 pounds)



Other specs

Color optionsOrange/gray/white
StarterElectric
