Kawasaki VN1700 Classic Tourer - 2009 Specifications and Reviews
General information | |
| Category: | Touring |
| Year: | 2009 |
| Model: | Kawasaki VN1700 Classic Tourer |
Engine and Transmission Specifications | |
| Transmission typefinal drive: | Belt |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Lubrication system: | Forced lubrication, semi-dry sump |
| Starter: | Electric |
| Fuel control: | SOHC |
| Valves per cylinder: | 4 |
| Fuel system: | Injection. Digital fuel injection, dual 42mm throttle bodies |
| Bore x stroke: | 102.0 x 104.0 mm (4.0 x 4.1 inches) |
| Compression: | 9.5:1 |
| Torque: | 136.00 |
| Stroke: | 4 |
| Engine type: | V2 |
| Capacity: | 1700.00 ccm (103.73 cubic inches) |
Physical measures and capacities | |
| Wheelbase: | 1,666 mm (65.6 inches) |
| Ground clearance: | 140 mm (5.5 inches) |
| Overall length: | 2,499 mm (98.4 inches) |
| Overall height: | 1,466 mm (57.7 inches) |
| Seat height: | 721 mm (28.4 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc: | 365.1 kg (804.8 pounds) |
Kawasaki VN1700 Classic Tourer dimensions and frame | |
| Rear brakes diameter: | 300 mm (11.8 inches) |
| Rear brakes: | Single disc |
| Front brakes diameter: | 300 mm (11.8 inches) |
| Front brakes: | Double disc |
| Rear tyre dimensions: | 170/70-B16 |
| Front tyre dimensions: | 130/90-B16 |
| Rear suspension: | Swingarm with twin air-assisted shocks, with 4-way rebound damping / 3.1 in. |
| Front suspension: | 43mm hydraulic fork / 5.5 in. |
| Rake (fork angle): | 30.0° |
| Frame type: | Double-cradle, steel |
Speed and acceleration | |
| Color options: | Black, red/beige |
| Fuel capacity: | 20.06 litres (5.30 gallons) |
