Touring Motorcycles

2009Kawasaki VN 1700 Voyager

25 fields on record

The 2009 Kawasaki VN 1700 Voyager is a heavyweight cruiser-touring motorcycle designed for riders seeking extended comfort and commanding presence on the open road. Its massive 1700cc V-twin engine delivers impressive low-end torque ideal for relaxed cruising, while its rigid steel frame and liquid-cooled technology ensure reliability on long-distance journeys. Best known for blending classic cruiser styling with practical touring capability, it suits experienced riders prioritizing comfort and stability.

Capacity: 1700.0 ccm
Engine: V -Twin twin, four-stroke
Gearbox: 6-speed
Dry weight: Not on record
Know it? Add it →
Seat height: Not on record
Know it? Add it →
Power: 139.0 HP

⇄ Compare with another bike All model years

Other years 2009 2010 2011 2013 2014

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail3%

Cornering35%

City riding30%

Daily riding55%

Touring96%

Two-up95%

Track5%

Best for: A full-dress touring bagger built for long-haul highway miles two-up, with fairing, hard luggage and huge torque for effortless cruising.
Built for: Big, plush, torque-rich American-style V-twin tourer. Smooth liquid-cooled 1700cc engine and belt drive make relaxed, unhurried mile-eating its calling.
Not ideal for: Not for off-road, track days, tight-city darting or anyone wanting a light, nimble, sporty ride. Its mass punishes low-speed maneuvering.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Full specifications

Engine

Capacity: 1700.0 ccm
Power: 139.0 HP
Torque: 146.2 Nm (14.9 kgf-m)
Engine type: V -Twin twin, four-stroke
Bore x stroke: 102.0 x 104.0 mm
Compression: 9.5:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Valves per cylinder: 4

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt

Dimensions & weight

Fuel capacity: 20.10 litres
Seat height: Not on record - add it
Dry weight: Not on record - add it

Chassis & suspension

Frame: Steel, double-cradle with box-section single-tube backbone
Front suspension: Hydraulic fork
Rear suspension: Swingarm with twin air-assisted shocks, with 4-way rebound damping
Rake (fork angle): 30.0°

Brakes & wheels

Front brakes: Double disc
Front brakes diameter: 300 mm
Rear brakes: Single disc
Rear brakes diameter: 300 mm
Front tyre: 130/90-16
Rear tyre: 170/70-16

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2009	2010	2011	2013	2014
Capacity	1700.00 ccm (103.73 cubic inches)	1700.00 ccm (103.73 cubic inches)	1700.00 ccm (103.73 cubic inches)	1700.00 ccm (103.73 cubic inches)	1700.00 ccm (103.73 cubic inches)
Seat height	—	—	—	730 mm (28.7 inches)	730 mm (28.7 inches)
Fuel capacity	20.06 litres (5.30 gallons)	20.00 litres (5.28 gallons)	20.00 litres (5.28 gallons)	20.00 litres (5.28 gallons)	20.00 litres (5.28 gallons)
Color options	—	Saphire blue/gray	Black	White/silver	White/silver
