Kawasaki Vulcan 1700 Nomad - 2010 Specifications and Reviews
General information | |
| Category: | Touring |
| Year: | 2010 |
| Model: | Kawasaki Vulcan 1700 Nomad |
Engine and Transmission Specifications | |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Ignition: | TCBI with Digital Advance |
| Fuel control: | SOHC |
| Fuel system: | Injection |
| Bore x stroke: | 102.0 x 104.0 mm (4.0 x 4.1 inches) |
| Compression: | 9.5:1 |
| Torque: | 146.44 Nm (14.9 kgf-m or 108.0 ft.lbs) @ 2750 |
| Engine type: | V2, four-stroke |
| Capacity: | 1700.00 ccm (103.73 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes: | Single disc |
| Front brakes: | Double disc |
| Rear tyre dimensions: | 170/70-16 |
| Front tyre dimensions: | 130/90-16 |
| Rear suspension: | Swingarm with twin air-assisted shocks, with 4-way rebound damping / 3.1 in. |
| Front suspension: | 43mm hydraulic fork / 5.5 in. |
| Rake (fork angle): | 30.0° |
| Frame type: | Steel, double-cradle with box-section single-tube backbone |
Physical measures and capacities | |
| Fuel capacity: | 20.06 litres (5.30 gallons) |
| Wheelbase: | 1,666 mm (65.6 inches) |
| Overall width: | 1,026 mm (40.4 inches) |
| Overall length: | 2,499 mm (98.4 inches) |
| Overall height: | 1,466 mm (57.7 inches) |
| Seat height: | 729 mm (28.7 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc: | 378.3 kg (834.0 pounds) |
Other specs | |
| Color options: | 2-tone Metallic Diablo Black/Metallic Titanium |
| Starter: | Electric |
