Kawasaki Vulcan S ABS Special Edition - 2018 Specifications and Reviews

2018

2017

Kawasaki Vulcan S ABS Special Edition 2018 24263 Thumb

General information
Category:	Custom / cruiser
Year:	2018
Model:	Kawasaki Vulcan S ABS Special Edition
Engine and Transmission Specifications
Driveline:	Sealed chain
Clutch:	Wet multi-disc
Transmission type,final drive:	Chain
Gearbox:	6-speed
Cooling system:	Liquid
Ignition:	TCBI with digital advance
Fuel control:	Double Overhead Cams/Twin Cam (DOHC)
Fuel system:	Injection. DFI® 38mm throttle bodies (2), with sub-throttle valves
Valves per cylinder:	4
Bore x Stroke:	83.0 x 60.0 mm (3.3 x 2.4 inches)
Compression:	10.8:1
Torque:	63.00 Nm (6.4 kgf-m or 46.5 ft.lbs) @ 6600 Revolutions">RPM
Power:	61.00 Horsepower">HP (44.5 Kilowatt">kW)) @ 7500 Revolutions">RPM
Engine type:	Twin, four-stroke
Brakes, suspension, Frame and wheels
Rear brakes diameter:	250 mm (9.8 inches)
Rear brakes:	Single disc. Single-piston caliper. ABS.
Front brakes diameter:	300 mm (11.8 inches)
Front brakes:	Double disc. Two-piston calipers. ABS.
Rear tyre:	160/60-17
Front tyre:	120/70-18
Rear wheel travel:	81 mm (3.2 inches)
Rear Suspension:	Lay-down offset rear shock with linkage and adjustable preload
Front wheel travel:	130 mm (5.1 inches)
Front Suspension:	41mm telescopic fork
Trail:	119 mm (4.7 inches)
Rake (fork angle):	31.0°
Frame type:	Tubular diamond, high-tensile steel

Physical measures and capacities
Fuel capacity:	14.00 litres (3.70 gallons)
Wheelbase:	1,575 mm (62.0 inches)
Ground clearance:	130 mm (5.1 inches)
Overall width:	881 mm (34.7 inches)
Overall length:	2,311 mm (91.0 inches)
Overall height:	1,100 mm (43.3 inches)
Seat height:	705 mm (27.8 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:	226.0 kg (498.3 pounds)
Other specs
Factory warranty:	12 Month Limited Warranty
Starter:	Electric
Color options:	Pearl Lava Orange
