Suzuki Boulevard M109R Limited Edition - 2007 Specifications and Reviews

4.5 stars Average rating: 4.5 from 2 votes
.

General information

CategoryCustom / cruiser
Year2007
ModelSuzuki Boulevard M109R Limited Edition

Engine and Transmission Specifications

Transmission typefinal driveShaft drive (cardan)
Gearbox5-speed
Cooling systemLiquid
Lubrication systemSemi-Dry Sump
IgnitionDigital/transistorized
Fuel controlDOHC
Fuel systemInjection
Bore x stroke112.0 x 90.5 mm (4.4 x 3.6 inches)
Compression10.5:1
Stroke4
Engine typeV2
Capacity:1783.00 ccm (108.80 cubic inches)

Physical measures and capacities

Wheelbase1,710 mm (67.3 inches)
Ground clearance130 mm (5.1 inches)
Overall width875 mm (34.4 inches)
Overall length2,450 mm (96.5 inches)
Overall height1,185 mm (46.7 inches)
Seat height705 mm (27.8 inches) If adjustable, lowest setting.
Dry weight319.0 kg (703.3 pounds)



Suzuki Boulevard M109R Limited Edition dimensions and frame

Rear brakesSingle disc
Front brakesDouble disc
Rear tyre dimensions240/40-R18
Front tyre dimensions130/70-R18
Rear suspensionLink type, coil spring, oil damped, 7 way adjustable spring pre-load
Front suspensionInverted telescopic, coil spring, oil damped

Speed and acceleration

Color optionsBlue/White
Fuel capacity19.50 litres (5.15 gallons)
