Suzuki Boulevard M50 - 2005 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2005
Model:Suzuki Boulevard M50

Engine and Transmission Specifications

Transmission typefinal drive:Shaft drive (cardan)
Gearbox:5-speed
Cooling system:Liquid
Starter:Electric
Fuel control:SOHC
Valves per cylinder:4
Fuel system:Injection
Bore x stroke:83.0 x 74.4 mm (3.3 x 2.9 inches)
Compression:9.4:1
Stroke:4
Engine type:V2
Capacity:819.40 ccm (50.00 cubic inches)


Physical measures and capacities

Wheelbase:1,655 mm (65.2 inches)
Ground clearance:140 mm (5.5 inches)
Overall width:860 mm (33.9 inches)
Overall length:2,370 mm (93.3 inches)
Overall height:1,130 mm (44.5 inches)
Seat height:700 mm (27.6 inches) If adjustable, lowest setting.
Dry weight:245.0 kg (540.1 pounds)


Suzuki Boulevard M50 dimensions and frame

Rear brakes:Single disc
Front brakes:Single disc
Rear tyre dimensions:170/80-15
Front tyre dimensions:130/90-16
Rear suspension:Link-type, oil damped, 7-way adjustable spring preload
Front suspension:Inverted, telescopic, coil spring, oil damped
Frame type:Soft-tail-style frame creates a continuous flowing line from the headlight, through the fuel tank, seat and rear fender

Speed and acceleration

Color options:Blue, Red
Fuel capacity:15.50 litres (4.10 gallons)
