Suzuki Intruder M800 - 2006 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2006
Model:Suzuki Intruder M800


Engine and Transmission Specifications

Clutch:Wet multi plate
Transmission typefinal drive:Shaft drive (cardan)
Gearbox:5-speed
Cooling system:Air
Ignition:Electronic ignition (transistorized)
Fuel control:OHC
Fuel system:Injection
Bore x stroke:83.0 x 74.4 mm (3.3 x 2.9 inches)
Compression:9.4:1
Torque:69.00
Power:55.00
Stroke:4
Engine type:V2
Capacity:805.00 ccm (49.12 cubic inches)


Physical measures and capacities

Wheelbase:1,655 mm (65.2 inches)
Ground clearance:135 mm (5.3 inches)
Overall width:860 mm (33.9 inches)
Overall length:2,370 mm (93.3 inches)
Overall height:1,130 mm (44.5 inches)
Alternate seat height:805 mm (31.7 inches) If adjustable, highest setting.
Seat height:700 mm (27.6 inches) If adjustable, lowest setting.
Dry weight:245.0 kg (540.1 pounds)

Suzuki Intruder M800 dimensions and frame

Rear brakes diameter:180 mm (7.1 inches)
Rear brakes:Expanding brake (drum brake)
Front brakes diameter:300 mm (11.8 inches)
Front brakes:Single disc
Rear suspension:Link type, oil damped, coil spring, spring pre-load 7-way adjustable
Front suspension:Inverted telescopic, coil spring
Rake (fork angle):32.3°

Speed and acceleration

Power/weight ratio:0.2245 HP/kg

Other specs

Fuel capacity:15.50 litres (4.10 gallons)
