General information | |
| Category: | Sport |
| Year: | 2006 |
| Model: | Suzuki SV 1000 SZ |
Engine and Transmission Specifications | |
| Clutch: | Wet multi plate |
| Transmission typefinal drive: | Chain |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Lubrication system: | Wet sump |
| Starter: | Electric |
| Ignition: | Digital electronic |
| Fuel control: | DOHC |
| Valves per cylinder: | 4 |
| Fuel system: | Injection |
| Bore x stroke: | 98.0 x 66.0 mm (3.9 x 2.6 inches) |
| Compression: | 11.6:1 |
| Torque: | 102.00 |
| Power: | 167.76 |
| Stroke: | 4 |
| Engine type: | V2 |
| Capacity: | 996.00 ccm (60.78 cubic inches) |
Physical measures and capacities | |
| Wheelbase: | 1,430 mm (56.3 inches) |
| Ground clearance: | 150 mm (5.9 inches) |
| Overall width: | 745 mm (29.3 inches) |
| Overall length: | 2,085 mm (82.1 inches) |
| Overall height: | 1,170 mm (46.1 inches) |
| Alternate seat height: | 805 mm (31.7 inches) If adjustable, highest setting. |
| Seat height: | 800 mm (31.5 inches) If adjustable, lowest setting. |
| Dry weight: | 187.0 kg (412.3 pounds) |
Suzuki SV 1000 SZ dimensions and frame | |
| Rear brakes diameter: | 220 mm (8.7 inches) |
| Rear brakes: | Single disc |
| Front brakes diameter: | 310 mm (12.2 inches) |
| Front brakes: | Double disc |
| Rear suspension: | Link type, coil spring, oil damped, fully adjustable |
| Front suspension: | Conventional 46 mm telescopic. Fully adjustable |
| Rake (fork angle): | 24.5° |
Speed and acceleration | |
| Power/weight ratio: | 0.8971 HP/kg |
Other specs | |
| Fuel capacity: | 17.00 litres (4.49 gallons) |
