Category: | Sport |
Year: | 2006 |
Model: | Suzuki SV 1000 SZ |
|
Engine and Transmission Specifications |
Clutch: | Wet multi plate |
Transmission typefinal drive: | Chain |
Gearbox: | 6-speed |
Cooling system: | Liquid |
Lubrication system: | Wet sump |
Starter: | Electric |
Ignition: | Digital electronic |
Fuel control: | DOHC |
Valves per cylinder: | 4 |
Fuel system: | Injection |
Bore x stroke: | 98.0 x 66.0 mm (3.9 x 2.6 inches) |
Compression: | 11.6:1 |
Torque: | 102.00 |
Power: | 167.76 |
Stroke: | 4 |
Engine type: | V2 |
Capacity: | 996.00 ccm (60.78 cubic inches) |
|
Physical measures and capacities |
Wheelbase: | 1,430 mm (56.3 inches) |
Ground clearance: | 150 mm (5.9 inches) |
Overall width: | 745 mm (29.3 inches) |
Overall length: | 2,085 mm (82.1 inches) |
Overall height: | 1,170 mm (46.1 inches) |
Alternate seat height: | 805 mm (31.7 inches) If adjustable, highest setting. |
Seat height: | 800 mm (31.5 inches) If adjustable, lowest setting. |
Dry weight: | 187.0 kg (412.3 pounds) |
Suzuki SV 1000 SZ dimensions and frame |
Rear brakes diameter: | 220 mm (8.7 inches) |
Rear brakes: | Single disc |
Front brakes diameter: | 310 mm (12.2 inches) |
Front brakes: | Double disc |
Rear suspension: | Link type, coil spring, oil damped, fully adjustable |
Front suspension: | Conventional 46 mm telescopic. Fully adjustable |
Rake (fork angle): | 24.5° |
Speed and acceleration |
Power/weight ratio: | 0.8971 HP/kg |
Other specs |
Fuel capacity: | 17.00 litres (4.49 gallons) |
