Titan Sidewinder Softail Chopper - 2006 Specifications and Reviews

2006
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2006
Model:Titan Sidewinder Softail Chopper


Engine and Transmission Specifications

Greenhouse gases:175.9 CO
Fuel consumption:7.58 litres/100 km (13.2 km/l or 31.03 mpg)
Gearbox:6-speed
Cooling system:Air
Fuel control:OHV
Fuel system:Carburettor
Valves per cylinder:2
Bore x stroke:101.6 x 113.0 mm (4.0 x 4.5 inches)
Compression:9.8:1
Torque:121.00 Nm (12.3 kgf-m or 89.2 ft.lbs) @ 4000
Power:112.00
Engine type:V2, four-stroke
Capacity:1750.00 ccm (106.79 cubic inches)

Brakes, suspension, Frame and wheels

Rear brakes diameter:292 mm (11.5 inches)
Rear brakes:Single disc. 4-piston calipers
Front brakes diameter:330 mm (13.0 inches)
Front brakes:Single disc. 4-piston calipers
Front tyre dimensions:110/90-19
Rear suspension:Dual chromed agusta shocks
Front suspension:Inverted forks
Rake (fork angle):35.0°


Physical measures and capacities

Fuel capacity:17.41 litres (4.60 gallons)
Wheelbase:1,882 mm (74.1 inches)
Ground clearance:89 mm (3.5 inches)
Seat height:584 mm (23.0 inches) If adjustable, lowest setting.
Power/weight ratio:0.3631 HP/kg
Dry weight:308.4 kg (680.0 pounds)

Other specs

Color options:Black, Rec, Blue, Red, Yellow
