Triumph Speedmaster - 2006 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2006
Model:Triumph Speedmaster


Engine and Transmission Specifications

Clutch:Wet. multi-plate
Transmission typefinal drive:Chain
Gearbox:5-speed
Cooling system:Air
Starter:Electric
Ignition:Digital - inductive type
Fuel control:DOHC
Fuel system:Carburettor
Bore x stroke:90.0 x 68.0 mm (3.5 x 2.7 inches)
Compression:9.2:1
Torque:69.00
Power:55.00
Stroke:4
Engine type:Twin
Capacity:865.00 ccm (52.78 cubic inches)

Physical measures and capacities

Wheelbase:1,655 mm (65.2 inches)
Overall width:830 mm (32.7 inches)
Overall length:2,420 mm (95.3 inches)
Overall height:1,160 mm (45.7 inches)
Seat height:720 mm (28.3 inches) If adjustable, lowest setting.
Dry weight:229.0 kg (504.9 pounds)

Triumph Speedmaster dimensions and frame

Rear brakes diameter:285 mm (11.2 inches)
Rear brakes:Single disc
Front brakes diameter:310 mm (12.2 inches)
Front brakes:Double disc
Rear tyre dimensions:170/80-R15
Front tyre dimensions:110/80-18
Rear suspension:Chromed spring twin shocks with adjustable preload
Front suspension:41mm forks
Rake (fork angle):33.3°
Frame type:Tubular steel cradle


Speed and acceleration

Power/weight ratio:0.2402 HP/kg

Other specs

Color options:Jet Black. Jet Black/Sunset Red. Jet Black/Neon Blue
Fuel capacity:16.60 litres (4.39 gallons)
