Triumph Speedmaster - 2011 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2011
ModelTriumph Speedmaster

Engine and Transmission Specifications

DrivelineX ring chain. Primary drive: Gear.
ClutchWet. multi-plate
Transmission type,final driveChain
Gearbox5-speed
Cooling systemAir
IgnitionDigital-inductive type via engine management system
Fuel controlDOHC
Fuel systemInjection. Multipoint sequential electonic fuel injection with SAI
Bore x stroke90.0 x 68.0 mm (3.5 x 2.7 inches)
Compression9.2:1
Torque71.87 Nm (7.3 kgf-m or 53.0 ft.lbs) @ 3300
Power60.00
Engine typeIn-line three, four-stroke
Capacity:865.00 ccm (52.78 cubic inches)



Brakes, suspension, Frame and wheels

Rear brakes diameter285 mm (11.2 inches)
Rear brakesSingle disc
Front brakes diameter310 mm (12.2 inches)
Front brakesDouble disc
Rear tyre dimensions170/80-B15
Front tyre dimensions100/90-R19
Rear suspensionKayaba chromed spring twin shocks with adjustable preload. 96mm rear wheel travel
Front suspensionKayaba 41mm forks with polished lowers. 120mm travel
Rake (fork angle)33.4°
Frame typeTubular steel cradle

Physical measures and capacities

Fuel capacity19.30 litres (5.10 gallons)
Wheelbase1,598 mm (62.9 inches)
Overall width831 mm (32.7 inches)
Overall length2,365 mm (93.1 inches)
Overall height1,168 mm (46.0 inches)
Seat height688 mm (27.1 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc249.5 kg (550.0 pounds)



Other specs

CommentsSold in Germany
Dry weight226.0 kg (498.2 pounds)
WheelsStreet tyres
Rear tyre225/40-10
Front tyre165/70-10
Rear SuspensionAlu swing arm
Front SuspensionDouble A-arm
Valves per cylinder4
Bore x Stroke96.0 x 65.2 mm (3.8 x 2.6 inches)
Color optionsPhantom Black. Cranberry Red
StarterElectric
