Category: | Custom / cruiser |
Year: | 2007 |
Model: | Yamaha Road Star Silverado |
Engine and Transmission Specifications |
Transmission type,final drive: | Belt |
Gearbox: | 5-speed |
Cooling system: | Air |
Ignition: | Digital TCI |
Fuel control: | OHV |
Fuel system: | Carburettor. 40mm Mikuni CV w/throttle position sensor |
Bore x stroke: | 97.0 x 113.0 mm (3.8 x 4.4 inches) |
Compression: | 8.3:1 |
Engine type: | V2, four-stroke |
Capacity: | 1671.58 ccm (102.00 cubic inches) |
Brakes, suspension, Frame and wheels |
Rear brakes diameter: | 320 mm (12.6 inches) |
Rear brakes: | Single disc |
Front brakes diameter: | 298 mm (11.7 inches) |
Front brakes: | Double disc |
Rear tyre dimensions: | 150/80-16 |
Front tyre dimensions: | 130/90-16 |
Rear suspension travel: | 109 mm (4.3 inches) |
Rear suspension: | Single shock, link-type |
Front suspension travel: | 140 mm (5.5 inches) |
Front suspension: | 43mm Telescopic fork |
|
Physical measures and capacities |
Fuel capacity: | 20.06 litres (5.30 gallons) |
Wheelbase: | 1,689 mm (66.5 inches) |
Ground clearance: | 145 mm (5.7 inches) |
Overall width: | 980 mm (38.6 inches) |
Overall length: | 2,499 mm (98.4 inches) |
Overall height: | 1,501 mm (59.1 inches) |
Seat height: | 711 mm (28.0 inches) If adjustable, lowest setting. |
Dry weight: | 327.0 kg (721.0 pounds) |
Other specs |
Starter: | Electric |
