Yamaha Stratoliner - 2009 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Touring
Year:2009
Model:Yamaha Stratoliner

Engine and Transmission Specifications

Transmission typefinal drive:Belt
Gearbox:5-speed
Cooling system:Air
Ignition:TCI: Transistor Controlled Ignition
Fuel control:OHV
Valves per cylinder:4
Fuel system:Injection. Twin-bore fuel injection, w/throttle position sensor
Bore x stroke:100.0 x 118.0 mm (3.9 x 4.6 inches)
Compression:9.5:1
Stroke:4
Engine type:V2
Capacity:1851.85 ccm (113.00 cubic inches)


Physical measures and capacities

Wheelbase:1,715 mm (67.5 inches)
Overall width:1,100 mm (43.3 inches)
Overall length:2,581 mm (101.6 inches)
Overall height:1,514 mm (59.6 inches)
Seat height:706 mm (27.8 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:363.8 kg (802.0 pounds)

Yamaha Stratoliner dimensions and frame

Rear brakes diameter:320 mm (12.6 inches)
Rear brakes:Single disc
Front brakes diameter:298 mm (11.7 inches)
Front brakes:Double disc
Rear tyre dimensions:190/60-17
Front tyre dimensions:130/70-18
Rear suspension:Single shock, 4.3inch travel
Front suspension travel:130 mm (5.1 inches)
Front suspension:46mm telescopic fork with adjustable preload


Speed and acceleration

Color options:Liquid Silver/Pearl White
Fuel capacity:17.03 litres (4.50 gallons)
