Scooters
2006Daelim E-Five ATS
24 fields on record
The 2006 Daelim E-Five ATS is a compact 49cc two-stroke scooter designed for urban commuters and novice riders seeking practical city transportation. Known for its lightweight design and fuel efficiency, this air-cooled scooter excels in navigating congested streets with its nimble handling and accessible ergonomics. Its telescopic front suspension and belt-driven transmission make it an affordable, easy-to-maintain entry-level option.
- Capacity
- 49.0 ccm
- Engine
- Single, two-stroke
- Gearbox
- Not on record
Know it? Add it → - Dry weight
- 86.0 kg
- Seat height
- 775 mm
- Power
- 5.4 HP (4.0 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed purely for short-distance urban commuting and running errands rather than performance riding.
- Built for
- A simple, no-frills economy scooter that prioritizes light weight and manoeuvrability over speed or refinement.
- Not ideal for
- Not suitable for highway travel, long-distance touring, carrying a passenger comfortably, or any off-road use.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 49.0 ccm
- Power
- 5.4 HP (4.0 kW)
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.0628 HP/kg (dry)
- Bore x stroke
- 39.0 x 41.4 mm
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Kick
Transmission
- Final drive
- Belt
Dimensions & weight
- Wheelbase
- 1260 mm
- Overall length
- 1790 mm
- Overall width
- 685 mm
- Overall height
- 1130 mm
- Seat height
- 775 mm
- Dry weight
- 86.0 kg
- Fuel capacity
- 6.00 litres
- Ground clearance
- 131 mm
Chassis & suspension
- Front suspension
- Telescopic
- Rear suspension
- Unit swing arm
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 130/90-10
- Rear tyre
- 130/90-10
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
Rider Reviews
Common questions
What is the engine size of the Daelim E-Five ATS?
The 2006 Daelim E-Five ATS has a Capacity of 49.0 ccm (2.99 cubic inches).
What engine power does the Daelim E-Five ATS have?
The 2006 Daelim E-Five ATS has a Power of 5.4 HP (4.0 kW).
How much does the Daelim E-Five ATS weigh?
The 2006 Daelim E-Five ATS has a Dry weight of 86.0 kg (189.6 pounds).
