Underbones
2013Giantco Bella
32 fields on record
The 2013 Giantco Bella is a lightweight underbone for commuters who want frugal, practical step-through transport. Its 110cc air-cooled single makes 7 hp and 6.9 Nm, with a 95 kg dry weight and a 4.5-litre tank.
- Capacity
- 110.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 4-speed
- Dry weight
- 95.0 kg
- Seat height
- Not on record
Know it? Add it → - Power
- 7.0 HP (5.1 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for economical everyday transport, with step-through practicality and low running costs.
- Built for
- An underbone from Giantco with a 110cc engine; its character is easy-going and economical, with 7 hp on tap.
- Not ideal for
- Not for motorway speeds, long trips or off-road riding.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 110.0 ccm
- Power
- 7.0 HP (5.1 kW)
- Torque
- 6.9 Nm (0.7 kgf-m) @ 6000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.0737 HP/kg (dry)
- Bore x stroke
- 52.4 x 49.5 mm
- Compression
- 9.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CDI
- Valves per cylinder
- 2
Transmission
- Gearbox
- 4-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1280 mm
- Overall length
- 1940 mm
- Overall width
- 670 mm
- Overall height
- 1100 mm
- Dry weight
- 95.0 kg
- Fuel capacity
- 4.50 litres
- Oil capacity
- 0.80 litres
- Seat height
- Not on record - add it
Chassis & suspension
- Frame
- Steel
- Front suspension
- Oil damped telescopic fork
- Rear suspension
- Oil damped coil spring
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 2.50-17
- Rear tyre
- 2.75-17
Other
- Color options
- Grey
- Comments
- Chinese brand.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
Rider Reviews
Common questions
What is the engine size of the Giantco Bella?
The 2013 Giantco Bella has a Capacity of 110.0 ccm (6.71 cubic inches).
What engine power does the Giantco Bella have?
The 2013 Giantco Bella has a Power of 7.0 HP (5.1 kW).
How many gears does the Giantco Bella have?
The 2013 Giantco Bella has a Gearbox of 4-speed.
What is the torque of the Giantco Bella?
The 2013 Giantco Bella has a Torque of 6.9 Nm (0.7 kgf-m or 5.1 ft.lbs) @ 6000 RPM.
How much does the Giantco Bella weigh?
The 2013 Giantco Bella has a Dry weight of 95.0 kg (209.4 pounds).
