Naked Motorcycles
2016Hanway Raw 50
28 fields on record
The 2016 Hanway Raw 50 is an affordable Chinese-made commuter scooter ideal for new riders and urban commuters seeking economical transportation. Its compact dimensions, low 720mm seat height, and lightweight 102kg frame make it accessible and easy to handle. Known for its practicality and reliability, this entry-level bike offers excellent value with dual electric and kick starting.
- Capacity
- 49.5 ccm
- Engine
- Single, two-stroke
- Gearbox
- Not on record
Know it? Add it → - Dry weight
- 102.0 kg
- Seat height
- 720 mm
- Power
- 3.2 HP (2.4 kW) @ 8000 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built as a low-powered, low-speed runabout or learner moped rather than a serious performance or adventure machine.
- Built for
- A humble, unassuming little all-rounder that prioritizes simplicity and approachability over excitement or capability.
- Not ideal for
- This bike is not suitable for highway travel, touring, carrying a passenger, or anyone seeking real speed or off-road performance.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 49.5 ccm
- Power
- 3.2 HP (2.4 kW) @ 8000 RPM
- Torque
- 3.1 Nm (0.3 kgf-m) @ 6000 RPM
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.0314 HP/kg (dry)
- Compression
- 7.3:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CDI
Transmission
- Final drive
- Chain
Performance
- Top speed
- 45.0 km/h (28.0 mph)
Dimensions & weight
- Wheelbase
- 1355 mm
- Overall length
- 2060 mm
- Overall width
- 800 mm
- Seat height
- 720 mm
- Dry weight
- 102.0 kg
- Fuel capacity
- 12.00 litres
- Ground clearance
- 120 mm
Chassis & suspension
- Front suspension
- Telescopic forks
- Rear suspension
- Telescopic coil spring, oil damped
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Expanding brake (drum brake). Optional disc brake
- Front tyre
- 90/90-18
- Rear tyre
- 120/80-16
Other
- Color options
- Black/dark red, silver/dark grey
- Comments
- Chinese made bike.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
Rider Reviews
Common questions
What is the engine size of the Hanway Raw 50?
The 2016 Hanway Raw 50 has a Capacity of 49.5 ccm (3.02 cubic inches).
What engine power does the Hanway Raw 50 have?
The 2016 Hanway Raw 50 has a Power of 3.2 HP (2.4 kW) @ 8000 RPM.
What is the torque of the Hanway Raw 50?
The 2016 Hanway Raw 50 has a Torque of 3.1 Nm (0.3 kgf-m or 2.3 ft.lbs) @ 6000 RPM.
How much does the Hanway Raw 50 weigh?
The 2016 Hanway Raw 50 has a Dry weight of 102.0 kg (224.9 pounds).
