2002Harley-Davidson FLSTF Fat Boy

Rate this bike

24 fields on record

The 2002 Harley-Davidson FLSTF Fat Boy is an iconic cruiser designed for riders seeking classic American style and commanding presence. Its 1449cc V-twin engine delivers impressive torque for relaxed highway riding, while the low-slung stance and wide tires define its unmistakable silhouette. Best known for blending vintage aesthetics with modern reliability, it appeals to experienced cruiser enthusiasts who value tradition and presence over speed.

Capacity: 1449.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 320.0 kg
Seat height: Not on record
Know it? Add it →
Power: 67.0 HP (49.3 kW)

⇄ Compare with another bike ＋ Add to garage All model years ⚠ Recalls listed (1)

What’s new for the 2002 Harley-Davidson FLSTF Fat Boy

vs the 2001

Spec	2001	2002
Power	63.0 HP (46.3 kW)	67.0 HP (49.3 kW)
Top speed	170.0 km/h (105.6 mph)	not listed
Seat height	647 mm (25.5 inches)	not listed

Other years 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding55%

Touring45%

Two-up55%

Track5%

Best for: Built for stylish boulevard cruising and short-to-medium rides where image and torque-driven presence matter more than outright speed.
Built for: A muscular, classic American cruiser that delivers strong low-end torque and a commanding presence rather than sharp handling or high-rev thrills.
Not ideal for: Not a fit for riders seeking agile cornering, off-road capability, or lightweight everyday maneuverability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Full specifications

Engine

Capacity: 1449.0 ccm
Power: 67.0 HP (49.3 kW)
Torque: 106.0 Nm (10.8 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2094 HP/kg (dry)
Bore x stroke: 95.3 x 101.6 mm
Compression: 8.8:1
Cooling system: Air
Fuel system: Carburettor
Starting: Electric

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt

Dimensions & weight

Wheelbase: 1630 mm
Overall length: 2396 mm
Dry weight: 320.0 kg
Fuel capacity: 18.90 litres
Ground clearance: 123 mm
Reserve fuel capacity: 1.90 litres
Seat height: Not on record - add it

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1999	2002	2005	2008	2011
Capacity	1338 cc	1449 cc	1449 cc	1584 cc	1584 cc
Dry weight	—	320 kg	320 kg	310 kg	315 kg
Seat height	680 mm	—	699 mm	—	699 mm
Fuel capacity	15.9 L	18.9 L	19.7 L	18.9 L	18.9 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 1 recall may apply

EQUIPMENT:OTHER:LABELSApr 2005 · 05V151000

CERTAIN SOFTAIL MOTORCYCLES FAIL TO COMPLY WITH THE REQUIREMENTS OF PART 567, 'CERTIFICATION.' THE VIN/CERTIFICATION LABEL CONTAINS INCORRECT TIRE SIZE AND INFLATION PRESSURES FOR THE FRONT WHEEL. THE LABEL STATES THE TIRE SIZE IS MT90B21 AND THE INFLATION PRESSURE AS 30 PSI, WHEREAS THE CORRECT TIRE SIZE IS MT90B16, AND THE CORRECT INFLATION PRESSURE IS 36 PSI.

Risk: THE CERTIFICATION LABEL IS INCORRECT GIVING IMPROPER INFORMATION.

Remedy: HARLEY- DAVIDSON WILL MAIL INSTRUCTIONS ALONG WITH CORRECTED FEDERAL CERTIFICATION LABEL. IF AN OWNER SO DESIRES, A DEALER CAN INSTALL THE LABEL FOR THEM. THE RECALL BEGAN ON JUNE 6, 2005. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

These recalls cover some 2002 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.

Source: NHTSA. View all Harley-Davidson recalls →
