Supermotos
2023Kawasaki KLX230SM
42 fields on record
The 2023 Kawasaki KLX230SM is a lightweight supermoto designed for beginner and intermediate riders seeking versatile street and light off-road capability. Its single-cylinder four-stroke engine delivers manageable power with excellent fuel efficiency, while the compact chassis and low seat height make it approachable for riders of various experience levels. The KLX230SM excels as an affordable urban commuter with genuine dirt-bike heritage and playful handling characteristics.
- Capacity
- 233.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 129.0 kg
- Seat height
- 846 mm
- Power
- 20.3 HP (14.9 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- This is a lightweight supermoto designed for playful street riding, urban commuting, and darting through tight corners rather than outright speed or distance.
- Built for
- A fun, flickable, low-displacement machine that rewards momentum-carrying riding style over raw power.
- Not ideal for
- It is not a good fit for riders wanting highway touring capability, a passenger-friendly setup, or strong straight-line acceleration.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 233.0 ccm
- Power
- 20.3 HP (14.9 kW)
- Torque
- 19.8 Nm (2.0 kgf-m) @ 6100 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1574 HP/kg (dry)
- Bore x stroke
- 67.0 x 66.0 mm
- Compression
- 9.4:1
- Cooling system
- Air
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- TCBI Electronic Advance
- Valves per cylinder
- 4
- Lubrication system
- Forced lubrication, wet sump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-disc, manual
Dimensions & weight
- Wheelbase
- 1374 mm
- Overall length
- 2050 mm
- Overall width
- 836 mm
- Overall height
- 1120 mm
- Seat height
- 846 mm
- Dry weight
- 129.0 kg
- Wet weight
- 134.0 kg
- Fuel capacity
- 7.60 litres
- Ground clearance
- 231 mm
Chassis & suspension
- Frame
- High-tensile steel, box-section perimeter
- Front suspension
- 37mm telescopic fork
- Rear suspension
- Uni-Trak® linkage system and single shock with adjustable spring preload
- Front wheel travel
- 203 mm
- Rear wheel travel
- 218 mm
- Rake (fork angle)
- 27.5°
- Trail
- 117 mm
Brakes & wheels
- Front brakes
- Single disc. Dual-piston. Petal disc. Optional ABS.
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. Single-piston. Petal disc. Optional ABS.
- ABS
- Optional
- Front tyre
- 110/70-17
- Rear tyre
- 120/70-17
Other
- Color options
- Lime Green, Oriental Blue
- Warranty
- 12
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2023 | 2024 | 2025 | 2026 | 2027 |
|---|---|---|---|---|---|
| Capacity | 233 cc | 233 cc | 233 cc | 233 cc | 233 cc |
| Dry weight | 129 kg | 129 kg | 129 kg | 130 kg | 130 kg |
| Seat height | 846 mm | 846 mm | 841 mm | 841 mm | 841 mm |
| Fuel capacity | 7.6 L | 7.6 L | 7.6 L | 7.6 L | 7.6 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Kawasaki KLX230SM?
The 2023 Kawasaki KLX230SM has a Capacity of 233.0 ccm (14.22 cubic inches).
What engine power does the Kawasaki KLX230SM have?
The 2023 Kawasaki KLX230SM has a Power of 20.3 HP (14.9 kW).
How many gears does the Kawasaki KLX230SM have?
The 2023 Kawasaki KLX230SM has a Gearbox of 6-speed.
What is the torque of the Kawasaki KLX230SM?
The 2023 Kawasaki KLX230SM has a Torque of 19.8 Nm (2.0 kgf-m or 14.6 ft.lbs) @ 6100 RPM.
How much does the Kawasaki KLX230SM weigh?
The 2023 Kawasaki KLX230SM has a Dry weight of 129.0 kg (284.4 pounds).
