Enduro Bikes
2009KTM 505 XC-F
34 fields on record
The 2009 KTM 505 XC-F is a hard-hitting 477cc single-cylinder enduro machine built for serious off-road riders seeking raw performance and reliability. Its potent four-stroke engine delivers aggressive power delivery through challenging terrain, while the lightweight construction and nimble handling make it equally capable in technical cross-country conditions. Known for durability and trail-proven engineering, it remains a benchmark middleweight for competitive enduro and off-road enthusiasts.
- Capacity
- 477.5 ccm
- Engine
- Single
- Gearbox
- 5-speed
- Dry weight
- 108.3 kg
- Seat height
- 985 mm
- Power
- 50.0 HP (36.8 kW)
What’s new for the 2009 KTM 505 XC-F
vs the 2008| Spec | 2008 | 2009 |
|---|---|---|
| Gearbox | 4-speed | 5-speed |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for cross-country and enduro racing, it excels at tackling trails, rough terrain, and technical off-road courses rather than paved commuting.
- Built for
- Sharp, light, and eager to change direction, it rewards an active riding style with race-oriented throttle response and nimble handling in tight terrain.
- Not ideal for
- It is a poor choice for new riders, highway travel, two-up riding, or anyone wanting plush comfort and low-effort daily commuting.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 477.5 ccm
- Power
- 50.0 HP (36.8 kW)
- Engine type
- Single
- Power/weight ratio
- 0.4617 HP/kg (dry)
- Bore x stroke
- 100.0 x 60.8 mm
- Compression
- 12.5:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- Kokusan digital SX
- Valves per cylinder
- 4
- Lubrication system
- Pressure lubrication with 2 Eaton pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-disc clutch, operated hydraulically
Dimensions & weight
- Wheelbase
- 1475 mm
- Seat height
- 985 mm
- Dry weight
- 108.3 kg
- Fuel capacity
- 9.00 litres
- Ground clearance
- 380 mm
Chassis & suspension
- Frame
- Central double-cradle-type 25CrMo4
- Front suspension
- WP USD, 48 mm
- Rear suspension
- WP monoshock PDS
- Front wheel travel
- 300 mm
- Rear wheel travel
- 335 mm
- Rake (fork angle)
- 26.5°
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 80/100-21
- Rear tyre
- 110/100-18
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2008 | 2009 |
|---|---|---|
| Capacity | 478 cc | 478 cc |
| Dry weight | 108 kg | 108 kg |
| Seat height | 985 mm | 985 mm |
| Fuel capacity | 9 L | 9 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 505 XC-F?
The 2009 KTM 505 XC-F has a Capacity of 477.5 ccm (29.14 cubic inches).
What engine power does the KTM 505 XC-F have?
The 2009 KTM 505 XC-F has a Power of 50.0 HP (36.8 kW).
How many gears does the KTM 505 XC-F have?
The 2009 KTM 505 XC-F has a Gearbox of 5-speed.
How much does the KTM 505 XC-F weigh?
The 2009 KTM 505 XC-F has a Dry weight of 108.3 kg (238.8 pounds).
