Trials Bikes
2016OSSA Factory R
31 fields on record
The 2016 OSSA Factory R is a lightweight Spanish trials bike designed for competitive and recreational off-road riders seeking precision handling. Known for its minimalist design and exceptional maneuverability, it features advanced Öhlins suspension and potent braking systems. Its ultra-low seat height and featherweight construction make it ideal for technical terrain navigation.
- Capacity
- 294.1 ccm
- Engine
- Single, two-stroke
- Gearbox
- 6-speed
- Dry weight
- 64.5 kg
- Seat height
- 655 mm
- Power
- 19.4 HP (14.3 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It exists purely to tackle technical, low-speed obstacle-based trial riding rather than any form of transportation or speed-oriented use.
- Built for
- It has the character of a precise, featherweight dance partner, responsive and nimble with instant reactions to throttle and body input.
- Not ideal for
- It is not suitable for riders wanting a comfortable seat, highway capability, passenger carrying, or any kind of long-distance road touring.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 294.1 ccm
- Power
- 19.4 HP (14.3 kW)
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.3008 HP/kg (dry)
- Bore x stroke
- 79.0 x 60.0 mm
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Kick
- Ignition
- Kokusan CDI digital magnetic flywheel
- Lubrication system
- Mix 0.9% 100% synthetic oil
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Hydraulic control
Dimensions & weight
- Wheelbase
- 1328 mm
- Seat height
- 655 mm
- Dry weight
- 64.5 kg
- Fuel capacity
- 2.60 litres
- Ground clearance
- 340 mm
Chassis & suspension
- Frame
- Tubular profile CR-Mo steel with pipe of cast aluminum and forged aluminum lower
- Front suspension
- Tech Suspension 39 mm fork, adjustable in compression and rebound.
- Rear suspension
- Variable progressive system with shock absorber. Öhlins TTX adjustable compression and rebound.
Brakes & wheels
- Front brakes
- Single disc. Four-piston calipers.
- Front brakes diameter
- 185 mm
- Rear brakes
- Single disc. Two-piston calipers.
- Rear brakes diameter
- 150 mm
- Front tyre
- 2.75-21
- Rear tyre
- 4.00-18
Other
- Color options
- Black/green
- Comments
- Spanish brand.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
Rider Reviews
Common questions
What is the engine size of the OSSA Factory R?
The 2016 OSSA Factory R has a Capacity of 294.1 ccm (17.95 cubic inches).
What engine power does the OSSA Factory R have?
The 2016 OSSA Factory R has a Power of 19.4 HP (14.3 kW).
How many gears does the OSSA Factory R have?
The 2016 OSSA Factory R has a Gearbox of 6-speed.
How much does the OSSA Factory R weigh?
The 2016 OSSA Factory R has a Dry weight of 64.5 kg (142.2 pounds).
