Concept
2015Quadro 4 Adventure
29 fields on record
The 2015 Quadro 4 is a unique four-wheeled adventure vehicle designed for riders seeking stability and confidence on varied terrain. Its innovative tilting suspension and dual-wheel configuration provide exceptional traction and control, making it ideal for explorers prioritizing safety and capability over traditional motorcycle agility. Best known for pioneering four-wheel motorcycle technology, it offers an accessible entry point for adventurous riders of all experience levels.
- Capacity
- 346.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- Not on record
Know it? Add it → - Dry weight
- 258.0 kg
- Seat height
- 770 mm
- Power
- 30.0 HP (21.9 kW) @ 7500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed as an experimental leaning quad aimed at stable, accessible urban and light touring mobility rather than performance riding.
- Built for
- It has a quirky, engineering-forward character built around tilting four-wheel stability and automatic operation rather than raw speed or sporting feedback.
- Not ideal for
- It is not for riders seeking sharp cornering agility, off-road capability, or high-speed performance from a conventional motorcycle.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 346.0 ccm
- Power
- 30.0 HP (21.9 kW) @ 7500 RPM
- Torque
- 24.5 Nm (2.5 kgf-m) @ 5000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1163 HP/kg (dry)
- Bore x stroke
- 82.0 x 65.5 mm
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Valves per cylinder
- 4
- Lubrication system
- Trochoid pump, wet-sump
Transmission
- Final drive
- Belt
- Clutch
- Automatic dry centrifugal
Dimensions & weight
- Overall length
- 2180 mm
- Overall height
- 1340 mm
- Seat height
- 770 mm
- Dry weight
- 258.0 kg
- Fuel capacity
- 15.00 litres
Chassis & suspension
- Frame
- Steel tubes
- Front suspension
- HTS (oleo-pneumatic tilting suspension)
- Rear suspension
- HTS (oleo-pneumatic tilting suspension)
- Rake (fork angle)
- 19.0°
Brakes & wheels
- Front brakes
- Double disc
- Rear brakes
- Single disc
- Front tyre
- 110/80-14
- Rear tyre
- 110/80-14
Other
- Color options
- Black
- Comments
- Two front and rear wheels. Windshied.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
Rider Reviews
Common questions
What is the engine size of the Quadro 4 Adventure?
The 2015 Quadro 4 Adventure has a Capacity of 346.0 ccm (21.11 cubic inches).
What engine power does the Quadro 4 Adventure have?
The 2015 Quadro 4 Adventure has a Power of 30.0 HP (21.9 kW) @ 7500 RPM.
What is the torque of the Quadro 4 Adventure?
The 2015 Quadro 4 Adventure has a Torque of 24.5 Nm (2.5 kgf-m or 18.1 ft.lbs) @ 5000 RPM.
How much does the Quadro 4 Adventure weigh?
The 2015 Quadro 4 Adventure has a Dry weight of 258.0 kg (568.8 pounds).
