Supermotos
2012TM Racing SMX 530F
24 fields on record
The 2012 TM Racing SMX 530 F is a lightweight supermotard designed for competitive riders seeking agile handling and precise control in mixed terrain environments. Powered by a 527cc liquid-cooled single-cylinder four-stroke engine with DOHC technology, it delivers responsive performance through a carbureted fuel system and sophisticated electronic ignition. Best known for its nimble chassis and racing pedigree, this machine excels in enduro-supermotard competition and appeals to experienced pilots prioritizing maneuverability over outright power.
- Capacity
- 527.7 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- Not on record
Know it? Add it → - Seat height
- Not on record
Know it? Add it → - Power
- 58.0 HP (42.7 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed for tarmac supermoto competition and aggressive cornering play, not general-purpose transportation.
- Built for
- A raw, focused, race-bred machine that rewards precision and punishes hesitation, with sharp steering and a punchy big-bore thumper engine.
- Not ideal for
- This is not the bike for riders wanting comfort, passenger capability, long-distance touring range, or a forgiving, low-maintenance daily commuter.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 527.7 ccm
- Power
- 58.0 HP (42.7 kW)
- Engine type
- Single, four-stroke
- Bore x stroke
- 98.0 x 70.0 mm
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- Kokusan DCI Electronic with variable advance
- Valves per cylinder
- 4
- Lubrication system
- Dry sump with 2 pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiple-disk in oil-bath with hydraulic control
Dimensions & weight
Chassis & suspension
- Frame
- Aluminium perimetral
- Front suspension
- Marzocchi USD fork, 50mm
- Rear suspension
- Sachs Boge (optional Ohlins o TM)
Brakes & wheels
- Front brakes
- Single disc. Braking wave Disk. With Nissin pump and caliper
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. Braking wave Disk. With Nissin pump and caliper
- Rear brakes diameter
- 240 mm
Other
- Color options
- Blue/white/black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2016 |
|---|---|---|
| Capacity | 528 cc | 528 cc |
| Fuel capacity | 8.2 L | 8.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the TM Racing SMX 530F?
The 2012 TM Racing SMX 530F has a Capacity of 527.7 ccm (32.20 cubic inches).
What engine power does the TM Racing SMX 530F have?
The 2012 TM Racing SMX 530F has a Power of 58.0 HP (42.7 kW).
How many gears does the TM Racing SMX 530F have?
The 2012 TM Racing SMX 530F has a Gearbox of 5-speed.
