2023 Vertigo Dougie Lampkin Replica
- 300 ccCapacity
- 31 hp (22.6 kW)Power
- Not on recordTorque · add it
- 68 kgDry weight
- 680 mmSeat height

The 2023 Vertigo Dougie Lampkin Replica is a 300cc two-stroke trial bike engineered for experienced riders pursuing competitive trial riding. Named after legendary trials champion Dougie Lampkin, it features a lightweight multitubular steel frame, liquid-cooled engine producing 31 horsepower, and advanced suspension technology. Best known for its precision handling and technical performance in demanding trial competitions.
Check a bike by registration
Buying a used one? Enter its registration to see its MOT history and recorded mileage.
Engine
| Type | Single-cylinder, 2-stroke |
| Capacity | 300 cc |
| Bore x Stroke | 79 x 60 mm |
| Cooling | Liquid |
| Fuel system | Injection |
| Starter | Electric & kick |
Transmission
| Gearbox | 4-speed |
| Clutch | Multi-disc oil wet, adjustable preload |
Performance
| Max power | 31 hp (22.6 kW) @ 9,200 rpm |
| Power to weight | 0.46 hp/kg (dry) |
Chassis
| Frame | Multitubular silver chassis 25CrMo4 steel, aluminium 6082 subframe |
| Front suspension | Tech Factory |
| Rear suspension | Swingarm combined with REIGER 2 way monoshock with compression, rebound and spring preload adjustment |
| Front brake | Single disc. Hydraulic Braktec, 4-piston caliper |
| Rear brake | Single disc. 2-piston caliper |
| Tyres | 1.60-21 / 2.15-18 |
Dimensions
| Overall length | 2,010 mm |
| Wheelbase | 1,310 mm |
| Seat height | 680 mm |
Weights and capacities
| Dry weight | 68 kg |
| Fuel tank | 2.3 l |
Engine
- Capacity
- 300.0 ccm
- Power
- 31.0 HP (22.6 kW) @ 9200 RPM
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.4559 HP/kg (dry)
- Bore x stroke
- 79.0 x 60.0 mm
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric & kick
Transmission
- Gearbox
- 4-speed
- Transmission type
- Manual
- Clutch
- Multi-disc oil wet, adjustable preload
Dimensions & weight
- Wheelbase
- 1310 mm
- Overall length
- 2010 mm
- Seat height
- 680 mm
- Dry weight
- 68.0 kg
- Fuel capacity
- 2.30 litres
Chassis & suspension
- Frame
- Multitubular silver chassis 25CrMo4 steel, aluminium 6082 subframe
- Front suspension
- Tech Factory
- Rear suspension
- Swingarm combined with REIGER 2 way monoshock with compression, rebound and spring preload adjustment
- Front wheel travel
- 170 mm
- Rear wheel travel
- 170 mm
Brakes & wheels
- Front brakes
- Single disc. Hydraulic Braktec, 4-piston caliper
- Front brakes diameter
- 185 mm
- Rear brakes
- Single disc. 2-piston caliper
- Front tyre
- 1.60-21
- Rear tyre
- 2.15-18
Other
- Color options
- Green/black
- Comments
- Battery assisted.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
29 fields on record · last reviewed 18 Sep 2026 · See all 29 specifications
Reliability & safety
How the score works »No reliability score, safety recalls or owner complaints on record for this bike yet.
Check a bike by VIN »How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for technical observed-trial riding, tackling rocks, logs, steps and tight balance-based obstacles at near-walking pace.
- Built for
- A featherweight, high-revving two-stroke with razor-sharp response and no flywheel effect, rewarding precise clutch and throttle control over outright speed.
- Not ideal for
- It is not suitable for highway travel, daily commuting, carrying a passenger, or anyone wanting comfort, wind protection, or sustained speed.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Own one
Parts diagrams
No diagrams for this bike yet. See which bikes have them.
Browse parts »Add it to My Garage
Free logbook: service history, reminders, recall alerts and running costs.
Add to Garage »Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
Rider Reviews
Common questions
What is the engine size of the Vertigo Dougie Lampkin Replica?
The 2023 Vertigo Dougie Lampkin Replica has a Capacity of 300.0 ccm (18.31 cubic inches).
What engine power does the Vertigo Dougie Lampkin Replica have?
The 2023 Vertigo Dougie Lampkin Replica has a Power of 31.0 HP (22.6 kW) @ 9200 RPM.
How many gears does the Vertigo Dougie Lampkin Replica have?
The 2023 Vertigo Dougie Lampkin Replica has a Gearbox of 4-speed.
How much does the Vertigo Dougie Lampkin Replica weigh?
The 2023 Vertigo Dougie Lampkin Replica has a Dry weight of 68.0 kg (149.9 pounds).
Similar bikes
Same category, weighted similarity










The 2023 Vertigo Dougie Lampkin Replica is a stunning tribute to the legendary trials rider, Dougie Lampkin. This limited edition bike features top-of-the-line components and a design that closely mirrors Lampkin's own competition bike. The attention to detail is impeccable, with replica graphics and signature touches that make this bike a true collector's item for fans of the legendary rider.
In terms of performance, the 2023 Vertigo Dougie Lampkin Replica delivers an incredible riding experience. The lightweight frame and powerful engine make it a formidable machine on the trails, while the precision handling and responsive brakes give riders the confidence to tackle even the toughest obstacles. Whether you're a seasoned trials competitor or a dedicated fan of Dougie Lampkin, this replica bike is sure to impress with its high-performance capabilities and authentic design.
