Sport Tourers
2016Yamaha FJ-09
43 fields on record
The 2016 Yamaha FJ-09 is a sport-touring motorcycle designed for riders seeking versatility and comfort on long-distance adventures. Known for its agile handling, adjustable ergonomics, and practical features like a height-adjustable windshield and 12V outlet, it delivers strong fuel efficiency and reliable performance. Its aluminum frame and advanced suspension make it equally capable on winding roads and highway cruising.
- Capacity
- 847.0 ccm
- Engine
- In-line three-cylinder, four-stroke
- Gearbox
- 6-speed
- Wet weight
- 209.6 kg
- Seat height
- 846 mm
- Power
- 115.0 HP (83.9 kW) @ 10120 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for covering long road distances quickly and comfortably, with wind protection and an accommodating riding position.
- Built for
- A sport tourer from Yamaha with an 847cc engine; its character is strong and confident, with 115 hp on tap.
- Not ideal for
- Not for off-road riding or riders who want a light, minimal machine.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 847.0 ccm
- Power
- 115.0 HP (83.9 kW) @ 10120 RPM
- CO2 Emissions
- 124 CO2 g/km
- Torque
- 87.5 Nm (8.9 kgf-m) @ 8480 RPM
- Engine type
- In-line three-cylinder, four-stroke
- Fuel consumption
- 5.40 litres/100 km (18.5 km/l)
- Power/weight ratio
- 0.5487 HP/kg (wet)
- Bore x stroke
- 78.0 x 59.1 mm
- Compression
- 11.5:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- TCI
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Assist and Slipper Clutch
Dimensions & weight
Chassis & suspension
- Frame
- Aluminum twin-spar
- Front suspension
- 41mm fork, adjustable preload and rebound damping
- Rear suspension
- Single shock, adjustable preload and rebound damping
- Front wheel travel
- 137 mm
- Rear wheel travel
- 130 mm
- Rake (fork angle)
- 24.0°
- Trail
- 99 mm
Brakes & wheels
- Front brakes
- Double disc. ABS. Hydraulic.
- Front brakes diameter
- 298 mm
- Rear brakes
- Single disc. Hydraulic.
- Rear brakes diameter
- 245 mm
- ABS
- Yes
- Front tyre
- 120/70-ZR17
- Rear tyre
- 180/55-ZR17
Other
- Color options
- Raven, Matte Silver
- Warranty
- 12
- Comments
- Height-adjustable windshield, side fairing, adjustable riding position, 12V electrical outlet.
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2015 | 2016 | 2017 | 2018 |
|---|---|---|---|---|
| Capacity | 847 cc | 847 cc | 847 cc | 847 cc |
| Seat height | 846 mm | 846 mm | 846 mm | 846 mm |
| Fuel capacity | 18.2 L | 18.2 L | 18.2 L | 18.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha FJ-09?
The 2016 Yamaha FJ-09 has a Capacity of 847.0 ccm (51.69 cubic inches).
What engine power does the Yamaha FJ-09 have?
The 2016 Yamaha FJ-09 has a Power of 115.0 HP (83.9 kW) @ 10120 RPM.
How many gears does the Yamaha FJ-09 have?
The 2016 Yamaha FJ-09 has a Gearbox of 6-speed.
What is the torque of the Yamaha FJ-09?
The 2016 Yamaha FJ-09 has a Torque of 87.5 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8480 RPM.
How much does the Yamaha FJ-09 weigh?
The 2016 Yamaha FJ-09 has a Wet weight of 209.6 kg (462.1 pounds).
