Sport Tourers
2002Yamaha XJ 900 S Diversion
32 fields on record
The 2002 Yamaha XJ 900 S Diversion is a versatile sport-touring middleweight that blends aggressive styling with practical everyday usability. Its 892cc inline-four engine delivers reliable mid-range power ideal for commuting and weekend touring. This model appeals to riders seeking an accessible, affordable platform combining comfort with spirited performance.
- Capacity
- 892.0 ccm
- Engine
- In-line four, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 239.0 kg
- Seat height
- 795 mm
- Power
- 89.5 HP (65.8 kW) @ 8250 RPM
What’s new for the 2002 Yamaha XJ 900 S Diversion
vs the 2001| Spec | 2001 | 2002 |
|---|---|---|
| Torque | 84.0 Nm (8.6 kgf-m or 62.0 ft.lbs) | 83.3 Nm (8.5 kgf-m or 61.4 ft.lbs) |
| Top speed | 205.0 km/h (127.4 mph) | not listed |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a versatile sport-tourer that handles daily commuting, weekend rides, and longer highway journeys with equal competence.
- Built for
- A composed and unintimidating in-line four that delivers smooth, linear power without demanding sharp reflexes or aggressive inputs.
- Not ideal for
- Not the right choice for riders seeking razor-sharp cornering agility, off-road capability, or outright top-tier sportbike performance.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 892.0 ccm
- Power
- 89.5 HP (65.8 kW) @ 8250 RPM
- Torque
- 83.3 Nm (8.5 kgf-m)
- Engine type
- In-line four, four-stroke
- Power/weight ratio
- 0.3745 HP/kg (dry)
- Bore x stroke
- 68.5 x 60.5 mm
- Compression
- 10.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Valves per cylinder
- 2
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Shaft
Dimensions & weight
- Wheelbase
- 1505 mm
- Overall length
- 2230 mm
- Overall width
- 750 mm
- Overall height
- 1300 mm
- Seat height
- 795 mm
- Dry weight
- 239.0 kg
- Wet weight
- 280.0 kg
- Fuel capacity
- 24.00 litres
- Ground clearance
- 130 mm
Chassis & suspension
- Front wheel travel
- 140 mm
- Rear wheel travel
- 110 mm
Brakes & wheels
- Front brakes
- Dual disc
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 245 mm
- Front tyre
- 120/70-17 58V
- Rear tyre
- 130/70-18 63H
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 1996 | 1998 | 2000 | 2001 | 2002 | 2003 |
|---|---|---|---|---|---|---|
| Capacity | 892 cc | 892 cc | 892 cc | 892 cc | 892 cc | 892 cc |
| Dry weight | 239 kg | 239 kg | 239 kg | 239 kg | 239 kg | 239 kg |
| Seat height | 795 mm | 795 mm | 795 mm | 795 mm | 795 mm | 795 mm |
| Fuel capacity | 24 L | 24 L | 20 L | 24 L | 24 L | 24 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha XJ 900 S Diversion?
The 2002 Yamaha XJ 900 S Diversion has a Capacity of 892.0 ccm (54.43 cubic inches).
What engine power does the Yamaha XJ 900 S Diversion have?
The 2002 Yamaha XJ 900 S Diversion has a Power of 89.5 HP (65.8 kW) @ 8250 RPM.
How many gears does the Yamaha XJ 900 S Diversion have?
The 2002 Yamaha XJ 900 S Diversion has a Gearbox of 5-speed.
What is the torque of the Yamaha XJ 900 S Diversion?
The 2002 Yamaha XJ 900 S Diversion has a Torque of 83.3 Nm (8.5 kgf-m or 61.4 ft.lbs).
How much does the Yamaha XJ 900 S Diversion weigh?
The 2002 Yamaha XJ 900 S Diversion has a Dry weight of 239.0 kg (526.9 pounds).
