2023Yamaha XMAX 125 Tech MAX
39 fields on record
The 2023 Yamaha XMAX 125 Tech Max is a premium automatic scooter designed for urban commuters seeking style and modern technology. Its Euro 5 Blue Core engine delivers efficient performance with 12.1 HP, while advanced features like fuel injection and TCI ignition provide reliability. Best known for its refined handling and tech-forward appeal, it suits riders prioritizing comfort and practicality in daily city riding.
- Capacity
- 124.7 ccm
- Engine
- Single, four-stroke
- Gearbox
- Not on record
Know it? Add it → - Wet weight
- 167.0 kg
- Seat height
- 800 mm
- Power
- 12.1 HP (8.8 kW) @ 8000 RPM
What’s new for the 2023 Yamaha XMAX 125 Tech MAX
vs the 2022| Spec | 2022 | 2023 |
|---|---|---|
| Torque | 11.0 Nm (1.1 kgf-m or 8.1 ft.lbs) @ 6250 RPM | 11.2 Nm (1.1 kgf-m or 8.3 ft.lbs) @ 6000 RPM |
| Fuel capacity | 13.00 litres (3.43 US gallons) | 13.20 litres (3.49 US gallons) |
| Front brakes | Single disc | Single disc. ABS |
| Rear brakes | Single disc | Single disc. ABS |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for practical urban transport, with twist-and-go simplicity and everyday convenience.
- Built for
- A scooter from Yamaha with a 125cc engine, focused on convenience, easy handling and low running costs.
- Not ideal for
- Not for off-road use or long, fast motorway journeys.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 124.7 ccm
- Power
- 12.1 HP (8.8 kW) @ 8000 RPM
- Torque
- 11.2 Nm (1.1 kgf-m) @ 6000 RPM
- Engine type
- Single, four-stroke
- Fuel consumption
- 2.30 litres/100 km (43.5 km/l)
- Power/weight ratio
- 0.0725 HP/kg (wet)
- Bore x stroke
- 52.0 x 58.7 mm
- Compression
- 11.2:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- TCI
- Valves per cylinder
- 4
- Lubrication system
- Wet sump
Transmission
- Transmission type
- Automatic
- Final drive
- Belt
Dimensions & weight
- Wheelbase
- 1570 mm
- Overall length
- 2180 mm
- Overall width
- 795 mm
- Overall height
- 1410 mm
- Seat height
- 800 mm
- Wet weight
- 167.0 kg
- Fuel capacity
- 13.20 litres
- Ground clearance
- 140 mm
- Carrying capacity
- Illuminated storage for 2 full-face helmets
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Underbone
- Front suspension
- Telescopic forks
- Rear suspension
- Unit Swing
- Front wheel travel
- 110 mm
- Rear wheel travel
- 90 mm
Brakes & wheels
- Front brakes
- Single disc. ABS
- Front brakes diameter
- 267 mm
- Rear brakes
- Single disc. ABS
- ABS
- Yes
- Front tyre
- 120/70-15
- Rear tyre
- 140/70-14
Other
- Color options
- Power Grey, Dark Petrol
- Comments
- Windscreen. Traction Control. Keyless.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2021 | 2022 | 2023 | 2024 |
|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 125 cc | 125 cc |
| Seat height | 800 mm | 800 mm | 800 mm | 800 mm |
| Fuel capacity | 13 L | 13 L | 13.2 L | 13 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha XMAX 125 Tech MAX?
The 2023 Yamaha XMAX 125 Tech MAX has a Capacity of 124.7 ccm (7.61 cubic inches).
What engine power does the Yamaha XMAX 125 Tech MAX have?
The 2023 Yamaha XMAX 125 Tech MAX has a Power of 12.1 HP (8.8 kW) @ 8000 RPM.
What is the torque of the Yamaha XMAX 125 Tech MAX?
The 2023 Yamaha XMAX 125 Tech MAX has a Torque of 11.2 Nm (1.1 kgf-m or 8.3 ft.lbs) @ 6000 RPM.
How much does the Yamaha XMAX 125 Tech MAX weigh?
The 2023 Yamaha XMAX 125 Tech MAX has a Wet weight of 167.0 kg (368.2 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2023 Yamaha XMAX 125 Tech Max is a sleek and powerful scooter that is perfect for urban commuters and city riders. With its advanced technology and sporty design, this scooter offers a smooth and comfortable ride, making it an ideal choice for anyone looking for a practical and stylish mode of transportation. The Tech Max version comes with a range of high-tech features, including a digital dashboard, keyless ignition, and smartphone connectivity, making it one of the most advanced scooters on the market.
In addition to its modern features, the 2023 Yamaha XMAX 125 Tech Max also offers impressive performance, thanks to its 125cc engine and lightweight construction. Whether you're navigating through traffic or cruising on the open road, this scooter delivers agile handling and excellent fuel efficiency. Overall, the 2023 Yamaha XMAX 125 Tech Max is a top-notch scooter that combines cutting-edge technology with reliable performance, making it an excellent choice for riders who value both style and function in their daily commute.
