BMW F 700 GS - 2013 Specifications and Reviews
General information | |
| Category: | Enduro / offroad |
| Year: | 2013 |
| Model: | BMW F 700 GS |
Engine and Transmission Specifications | |
| Emission details: | Closed-loop 3-way catalytic converter, emission standard EU-3 |
| Greenhouse gases: | 90.9 CO |
| Fuel consumption: | 3.92 litres/100 km (25.5 km/l or 60.01 mpg) |
| Driveline: | Endless O-ring chain with shock damping in rear wheel hub |
| Clutch: | Multiple-disc clutch in oil bath, mechanically operated |
| Transmission type,final drive: | Chain |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Lubrication system: | Dry sump |
| Fuel control: | DOHC |
| Fuel system: | Injection. Electroinc intake pipe injection, digital engine management (BMS-K+) |
| Valves per cylinder: | 4 |
| Bore x stroke: | 82.0 x 75.6 mm (3.2 x 3.0 inches) |
| Compression: | 12.0:1 |
| Top speed: | 191.5 km/h (119.0 mph) |
| Torque: | 57.00 Nm (5.8 kgf-m or 42.0 ft.lbs) @ 5300 |
| Power: | 73.76 |
| Engine type: | Twin, four-stroke |
| Capacity: | 798.00 ccm (48.69 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels: | Cast aluminium wheels |
| Rear brakes diameter: | 265 mm (10.4 inches) |
| Rear brakes: | Single disc. ABS. Floating disc. Single-piston caliper. |
| Front brakes diameter: | 300 mm (11.8 inches) |
| Front brakes: | Double disc. ABS. Floating discs. Two-piston calipers. |
| Rear tyre dimensions: | 140/80-17 |
| Front tyre dimensions: | 110/80-19 |
| Rear suspension travel: | 170 mm (6.7 inches) |
| Rear suspension: | Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable |
| Front suspension travel: | 180 mm (7.1 inches) |
| Front suspension: | Telescopic fork, 41 mm |
| Trail: | 94 mm (3.7 inches) |
| Rake (fork angle): | 26.0° |
| Frame type: | Tubular steel space frame |
Physical measures and capacities | |
| Fuel capacity: | 15.90 litres (4.20 gallons) |
| Wheelbase: | 1,562 mm (61.5 inches) |
| Overall width: | 889 mm (35.0 inches) |
| Overall length: | 2,281 mm (89.8 inches) |
| Overall height: | 1,240 mm (48.8 inches) |
| Seat height: | 820 mm (32.3 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.3966 HP/kg |
| Weight incl. oil, gas, etc: | 209.1 kg (461.0 pounds) |
| Dry weight: | 186.0 kg (410.0 pounds) |
Other specs | |
| Color options: | Red, silver, gray |
| Electrical: | 12 V / 12 Ah, maintenance-free battery. |
| Starter: | Electric |
