Category: | Enduro / offroad |
Year: | 2015 |
Model: | BMW F 700 GS |
Engine and Transmission Specifications |
Emission details: | Closed-loop 3-way catalytic converter, emission standard EU-3 |
Greenhouse gases: | 90.5 CO2 g/km. (CO2 - Carbon dioxide emission) |
Fuel consumption: | 3.90 litres/100 km (25.6 km/l or 60.31 mpg) |
Driveline: | Endless O-ring chain with shock damping in rear wheel hub |
Clutch: | Multiple-disc clutch in oil bath, mechanically operated |
Transmission type,final drive: | Chain |
Gearbox: | 6-speed |
Cooling system: | Liquid |
Lubrication system: | Dry sump |
Fuel control: | Double Overhead Cams/Twin Cam (DOHC) |
Fuel system: | Injection. Electroinc intake pipe injection, digital engine management (BMS-K+) |
Valves per cylinder: | 4 |
Bore x Stroke: | 82.0 x 75.6 mm (3.2 x 3.0 inches) |
Compression: | 12.0:1 |
Top speed: | 191.5 km/h (119.0 mph) |
Torque: | 77.00 Nm (7.9 kgf-m or 56.8 ft.lbs) @ 5300 Revolutions">RPM |
Power: | 75.00 Horsepower">HP (54.7 Kilowatt">kW)) @ 7300 Revolutions">RPM |
Engine type: | Twin, four-stroke |
Capacity: | 798.00 ccm (48.69 cubic inches) |
|
Brakes, suspension, Frame and wheels |
Wheels: | Cast aluminium wheels |
Rear brakes diameter: | 265 mm (10.4 inches) |
Rear brakes: | Single disc. ABS. Floating disc. Single-piston caliper. |
Front brakes diameter: | 300 mm (11.8 inches) |
Front brakes: | Double disc. ABS. Floating discs. Two-piston calipers. |
Rear tyre: | 140/80-17 |
Front tyre: | 110/80-19 |
Rear wheel travel: | 170 mm (6.7 inches) |
Rear Suspension: | Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable |
Front wheel travel: | 170 mm (6.7 inches) |
Front Suspension: | Telescopic fork, 41 mm |
Trail: | 95 mm (3.7 inches) |
Rake (fork angle): | 26.0° |
Frame type: | Tubular steel space frame |
Physical measures and capacities |
Reserve fuel capacity: | 4.00 litres (1.06 gallons) |
Fuel capacity: | 16.00 litres (4.23 gallons) |
Wheelbase: | 1,562 mm (61.5 inches) |
Overall width: | 890 mm (35.0 inches) |
Overall length: | 2,280 mm (89.8 inches) |
Overall height: | 1,215 mm (47.8 inches) |
Seat height: | 820 mm (32.3 inches) If adjustable, lowest setting. |
Power/weight ratio: | 0.4032 HP/kg |
Weight incl. oil, gas, etc: | 209.0 kg (460.8 pounds) |
Dry weight: | 186.0 kg (410.1 pounds) |
Other specs |
Electrical: | 12 V / 12 Ah, maintenance-free battery. |
Color options: | Red, silver, gray |
