Harley-Davidson CVO Road Glide - 2018 Specifications and Reviews
2018
General information | |
| Category: | Touring |
| Year: | 2018 |
| Model: | Harley-Davidson CVO Road Glide |
Engine and Transmission Specifications | |
| Exhaust system: | Dual, with crossover |
| Greenhouse gases: | 141.5 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption: | 6.10 litres/100 km (16.4 km/l or 38.56 mpg) |
| Driveline: | Chain, 34/46 ratio primary drive |
| Clutch: | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive: | Belt |
| Gearbox: | 6-speed |
| Cooling system: | Oil & air |
| Lubrication system: | Dry sump |
| Fuel system: | Injection. ESPFI |
| Bore x Stroke: | 103.5 x 114.3 mm (4.1 x 4.5 inches) |
| Compression: | 10.2:1 |
| Torque: | 166.00 Nm (16.9 kgf-m or 122.4 ft.lbs) @ 3500 Revolutions">RPM |
| Power: | 105.00 Horsepower">HP (76.6 Kilowatt">kW)) @ 5450 Revolutions">RPM |
| Engine details: | Milwaukee-Eight™ 117 |
| Engine type: | V2, four-stroke |
Brakes, suspension, Frame and wheels | |
| Wheels: | Gloss Black and Contrast Chrome Knockout |
| Rear brakes: | Single disc. ABS. 4-piston |
| Front brakes: | Double disc. ABS. 4-piston |
| Rear tyre: | 180/55-B18 |
| Front tyre: | 130/60-B21 |
| Rear Suspension: | Twin shocks |
| Front Suspension: | Telescopic fork |
| Trail: | 173 mm (6.8 inches) |
| Rake (fork angle): | 26.0° |
Physical measures and capacities | |
| Oil capacity: | 4.90 litres (0.32 quarts) |
| Fuel capacity: | 22.71 litres (6.00 gallons) |
| Wheelbase: | 1,625 mm (64.0 inches) |
| Ground clearance: | 125 mm (4.9 inches) |
| Overall length: | 2,460 mm (96.9 inches) |
| Seat height: | 680 mm (26.8 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.2727 HP/kg |
| Weight incl. oil, gas, etc: | 401.0 kg (884.1 pounds) |
| Dry weight: | 385.0 kg (848.8 pounds) |
Other specs | |
| Comments: | Small windshield. Cruise control. Infotainment. USB. |
| Carrying capacity: | Hard saddle bags |
| Light: | High beam, running lights, front fender light, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system (optional), 6-speed, low fuel warning, cruise control (optional), ABS (optional) |
| Instruments: | Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light Tachometer with fuel, voltage, oil pressure and ambient air temperature gauges |
| Starter: | Electric |
| Color options: | Vivid Black, Orange Lava and amp; Gunship Gray |
