2009 Harley-Davidson FLHTC Electra Glide Classic

+ Add a photo

Touring Motorcycles

2009Harley-Davidson FLHTC Electra Glide Classic

34 fields on record

The 2009 Harley-Davidson FLHTC Electra Glide Classic is a heavyweight cruising tourer built for long-distance riders seeking classic American style. Its 1584cc V-twin engine delivers smooth, low-end torque ideal for relaxed highway cruising with passenger comfort as priority. Known for iconic styling and highway-proven reliability, it remains the definitive choice for traditional Harley touring enthusiasts.

Capacity: 1584.0 ccm
Engine: V -Twin twin, four-stroke
Gearbox: 6-speed
Dry weight: 375.0 kg
Seat height: 715 mm
Power: 75.0 HP

⇄ Compare with another bike All model years ⚠ Recalls listed (3)

What’s new for the 2009 Harley-Davidson FLHTC Electra Glide Classic

vs the 2008

Spec	2008	2009
Engine capacity	1573.25 ccm (96.00 cubic inches)	1584.0 ccm (96.66 cubic inches)
Torque	125.56	125.0 Nm (12.7 kgf-m or 92.2 ft.lbs)
Weight	358.8 kg (791.0 pounds)	375.0 kg (826.7 pounds)
Seat height	780 mm (30.7 inches)	715 mm (28.1 inches)
Fuel capacity	22.71 litres (6.00 gallons)	22.70 litres (6.00 US gallons)
Front suspension	—	41.3mm telescopic, cartridge-style damping
Front brakes	Single disc. Bremo 4-piston calipers	Double disc
Rear brakes	Single disc. Bremo 4-piston calipers	Single disc
Wheelbase	1,613 mm (63.5 inches)	1613 mm (63.5 inches)

Other years 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering35%

City riding35%

Daily riding60%

Touring98%

Two-up90%

Track10%

Best for: Built for effortless long-distance highway cruising with full weather protection and creature comforts rather than outright performance.
Built for: A classic American touring bagger with a big, torque-rich V-twin thump, chrome-laden styling, and a relaxed, unhurried riding demeanor.
Not ideal for: Not for riders seeking sharp cornering agility, off-road capability, or a lightweight, quick-handling motorcycle.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 715mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2009 Harley-Davidson FLHTC Electra Glide Classic, with a cramped knee angle of around 80 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1584.0 ccm
Power: 75.0 HP
Torque: 125.0 Nm (12.7 kgf-m)
Engine type: V -Twin twin, four-stroke
Power/weight ratio: 0.2000 HP/kg
Bore x stroke: 95.3 x 111.1 mm
Compression: 9.2:1
Cooling system: Air
Fuel system: Injection
Starting: Electric

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: 9-plate, wet

Dimensions & weight

Wheelbase: 1613 mm
Overall length: 2469 mm
Overall height: 1549 mm
Seat height: 715 mm
Dry weight: 375.0 kg
Fuel capacity: 22.70 litres
Ground clearance: 129 mm

Chassis & suspension

Frame: New mild steel, single spar rigid backbone with
Front suspension: 41.3mm telescopic, cartridge-style damping
Front wheel travel: 117 mm
Rear wheel travel: 76 mm
Rake (fork angle): 26.0°
Trail: 170 mm

Brakes & wheels

Front brakes: Double disc
Front brakes diameter: 300 mm
Rear brakes: Single disc
Rear brakes diameter: 300 mm
Front tyre: 130/80-B17
Rear tyre: 180/65-B16

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2002	2005	2007	2009	2010	2012
Capacity	1450.00 ccm (88.48 cubic inches)	1448.00 ccm (88.36 cubic inches)	1573.25 ccm (96.00 cubic inches)	1584.00 ccm (96.66 cubic inches)	1584.00 ccm (96.66 cubic inches)	1687.97 ccm (103.00 cubic inches)
Dry weight	352.3 kg (776.7 pounds)	352.0 kg (776.0 pounds)	334.8 kg (738.0 pounds)	375.0 kg (826.7 pounds)	375.0 kg (826.7 pounds)	375.1 kg (827.0 pounds)
Seat height	693 mm (27.3 inches)	735 mm (28.9 inches)	780 mm (30.7 inches)	715 mm (28.1 inches)	693 mm (27.3 inches)	693 mm (27.3 inches)
Fuel capacity	18.90 litres (4.99 gallons)	19.00 litres (5.02 gallons)	18.92 litres (5.00 gallons)	22.70 litres (6.00 gallons)	22.70 litres (6.00 gallons)	22.71 litres (6.00 gallons)
Color options	—	2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl	Vivid black, fire red pearl, Pacific blue pearl (new)	—	Vivid Black, Brilliant Silver Pearl, Flame Blue Pearl, Red Hot Sunglo, Flame Blue Pearl/Brilliant Silver Pearl	Vivid Black, Brilliant Silver Pearl, Ember Red Sunglo, Birch White/Midnight Pearl

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 3 open recalls

SERVICE BRAKES, HYDRAULIC:FLUIDJan 2018 · 18V076000

Harley-Davidson Motor Company (Harley-Davidson) is recalling all 2008-2011 Touring, CVO Touring and VSRC motorcycles equipped with anti-lock brakes (ABS), including Road King (FLHR), Road King Police (EFI) (FLHP), Road King Police (EFI) (FLHPE), Electra Glide Standard Police (EFI) (FLHTP), Electra Glide Classic (EFI) (FLHTC), Electra Glide Ultra Classic (EFI) (FLHTCU) and Street Glide (EFI) (FLHX), 2008 VROD (VRSCAWA), CVO Road King 4 (FLHRSE4), Night Rod (VRSCDA), CVO Ultra Classic 3 (FLHTCUSE3), Night Rod Special (VRSCDXA), 2008-2010 Road King Classic (EFI) (FLHRC), 2008-2009 Road Glide (EFI) (FLTR) and Electra Glide Standard (EFI) (FLHT), 2009-2010 V-Rod (VRSCAW), 2009 CVO Ultra Classic (FLHTCUSE4) and CVO Road Glide 3 (FLTRSE3), 2009-2011 Night Rod Special (VRSCDX) and V-Rod Muscle (VRSCF), 2010 CVO Ultra Classic 5 (FLHTCUSE5) and CVO Street Glide (FLHXSE), 2010-2011 Electra Glide Ultra Limited (FLHTK) and Road Glide Custom (FLTRX), 2011 Road Glide Ultra 103 (FLTRU103), Street Glide 103 (FLHX103), Road King Classic 103 (FLHRC103), CVO Ultra Classic 6 (FLHTCUSE6), CVO Road Glide Ultra (FLTRUSE), Road Glide Custom 103 (FLTRX103), and CVO Street Glide 2 (FLHXSE2) motorcycles. Deposits may form on components within the brake system if the DOT 4 brake fluid is not replaced for a prolonged period of time beyond the 2-year maintenance schedule specified in the Owners Manual.

Risk: These deposits may cause a valve within the ABS Hydraulic Control Unit to stick, reducing braking ability and increasing the risk of a crash.

Remedy: Harley-Davidson will notify owners, and dealers will flush the entire brake system with new Platinum Label DOT 4 brake fluid, free of charge. The recall began on February 14, 2018. Owners may contact Harley-Davidson customer service at 1-800-258-2464. Harley-Davidson's number for this recall is 0171.

EXTERIOR LIGHTING:BRAKE LIGHTS:SWITCHOct 2011 · 11V506000

HARLEY-DAVIDSON IS RECALLING CERTAIN MODEL YEAR 2009-2012 TOURING, CVO TOURING AND TRIKE VEHICLES MANUFACTURED FROM JUNE 6, 2008, THROUGH SEPTEMBER 16, 2011. SEE THE ABOVE LIST FOR THE MODELS INCLUDED IN THE RECALL. THE REAR BRAKE LIGHT SWITCH MAY BE EXPOSED TO EXCESSIVE HEAT FROM THE EXHAUST SYSTEM.

Risk: THE EXCESSIVE HEAT MAY CAUSE THE SWITCH TO NOT ACTIVATE THE BRAKE LAMP OR ACTIVATE THE BRAKE LAMP WHEN NO BRAKE IS APPLIED AND/OR CAUSE A BRAKE FLUID LEAK AT THE BRAKE LIGHT SWITCH, AFFECTING REAR BRAKE PERFORMANCE. EITHER CONDITION MAY INCREASE THE RISK OF A CRASH.

Remedy: HARLEY-DAVIDSON WILL NOTIFY OWNERS, AND DEALERS WILL A INSTALL A REAR BRAKE LIGHT SWITCH KIT, FREE OF CHARGE. THE SAFETY RECALL IS EXPECTED TO BEGIN DURING OCTOBER 31, 2011. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

FUEL SYSTEM, GASOLINE:STORAGE:TANK ASSEMBLY:MOUNTINGDec 2009 · 09V457000

HARLEY-DAVIDSON IS RECALLING CERTAIN MODEL YEAR 2009 AND 2010 TOURING FAMILY MOTORCYCLES, INCLUDING CVO TOURING AND TRIKE PRODUCTS, MANUFACTURED FROM JUNE 6, 2008 THROUGH NOVEMBER 19, 2009. THE FRONT FUEL TANK MOUNTS MAY DISTORT IN REACTION TO SEVERE FRAME DAMAGE FROM A FRONTAL COLLISION. THIS CONDITION MAY CAUSE A FUEL LEAK AT THE WELD OF THE FRONT BRACKET TO THE TUNNEL.

Risk: A FUEL LEAK IN THE PRESENCE OF AN IGNITION SOURCE MAY RESULT IN A FIRE, WHICH COULD LEAD TO INJURY OR DEATH TO THE RIDER.

Remedy: DEALERS WILL INSTALL A LEFT AND RIGHT BRACE, WHICH ARE INTENDED TO REDUCE FRONT MOUNT DISTORTION DURING CERTAIN CRASH CONDITIONS. THIS REPAIR WILL BE PERFORMED FREE OF CHARGE. THE SAFETY RECALL BEGAN ON DECEMBER 11, 2009. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

Source: NHTSA. View all Harley-Davidson recalls →
