2009 Harley-Davidson FLSTSB Softail Cross Bones

+ Add a photo

Cruisers

2009Harley-Davidson FLSTSB Softail Cross Bones

Rate this bike

38 fields on record

The 2009 Harley-Davidson FLSTSB Softail Cross Bones is a custom cruiser designed for riders seeking classic styling with modern performance. Powered by a 1584cc V-twin engine producing 120 lb-ft of torque, it delivers smooth, low-end power ideal for highway cruising. Known for its bobber-inspired aesthetic and lightweight frame, it appeals to traditionalists who value authentic design and comfortable long-distance riding.

Capacity: 1584.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 318.0 kg
Seat height: 676 mm
Power: 75.0 HP (55.2 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (1)

What’s new for the 2009 Harley-Davidson FLSTSB Softail Cross Bones

vs the 2008

Spec	2008	2009
Engine capacity	1573.3 ccm (96.01 cubic inches)	1584.0 ccm (96.66 cubic inches)
Torque	115.0 Nm (11.7 kgf-m or 84.8 ft.lbs)	120.0 Nm (12.2 kgf-m or 88.5 ft.lbs)
Dry weight	317.5 kg (700.0 pounds)	318.0 kg (701.1 pounds)
Seat height	767 mm (30.2 inches)	676 mm (26.6 inches)
Front suspension	—	Black leading link
Rear suspension	—	Hidden, horizontal-mounted, coil-over
Wheelbase	1638 mm (64.5 inches)	1630 mm (64.2 inches)

Other years 2008 2009 2010 2011

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering25%

City riding45%

Daily riding45%

Touring40%

Two-up30%

Track5%

Best for: This is a styling-forward custom cruiser built for boulevard cruising and making a visual statement rather than for outright speed or long-distance touring.
Built for: A rugged, blacked-out bobber-styled Harley with a rigid-look springer front end, minimal chrome, and old-school attitude aimed at riders who want distinctive retro custom style.
Not ideal for: Not a good fit for riders seeking sharp cornering ability, off-road capability, or a bike optimized for high-speed sport riding.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 676mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2009 Harley-Davidson FLSTSB Softail Cross Bones, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1584.0 ccm
Power: 75.0 HP (55.2 kW)
Torque: 120.0 Nm (12.2 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2358 HP/kg
Bore x stroke: 95.3 x 111.1 mm
Compression: 9.2:1
Cooling system: Air
Fuel system: Injection
Starting: Electric
Lubrication system: Pressurized, dry-sump

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: 9-plate, wet

Dimensions & weight

Wheelbase: 1630 mm
Overall length: 2330 mm
Seat height: 676 mm
Dry weight: 318.0 kg
Wet weight: 334.3 kg
Fuel capacity: 18.90 litres
Ground clearance: 125 mm
Oil capacity: 3.10 litres

Chassis & suspension

Frame: Mild steel tubular frame; rectangular section backbone; stamped,
Front suspension: Black leading link
Rear suspension: Hidden, horizontal-mounted, coil-over
Front wheel travel: 130 mm
Rear wheel travel: 109 mm
Rake (fork angle): 32.0°
Trail: 160 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: MT90-B16
Rear tyre: 200/55-R17

Other

Color options: Vivid Black, Dark Blue Pearl, Black Denim, Pewter Denim

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2008	2009	2010	2011
Capacity	1573.25 ccm (96.00 cubic inches)	1584.00 ccm (96.66 cubic inches)	1584.00 ccm (96.66 cubic inches)	1584.00 ccm (96.66 cubic inches)
Dry weight	317.5 kg (700.0 pounds)	318.0 kg (701.1 pounds)	318.0 kg (701.1 pounds)	317.5 kg (700.0 pounds)
Seat height	767 mm (30.2 inches)	676 mm (26.6 inches)	760 mm (29.9 inches)	765 mm (30.1 inches)
Fuel capacity	18.92 litres (5.00 gallons)	18.90 litres (4.99 gallons)	19.70 litres (5.20 gallons)	19.70 litres (5.20 gallons)
Color options	Vivid Black, Black Denim, Pewter Denim, Dark Blue Denim, Olive Pearl, Dark Blue Pearl	Vivid Black, Dark Blue Pearl, Black Denim, Pewter Denim	Vivid Black, Brilliant Silver Pearl, Black Denim, Black Ice Denim	Vivid Black, Cool Blue Pearl, Sedona Orange, Black Denim

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 1 open recall

SERVICE BRAKES, HYDRAULICJun 2009 · 09V211000

HARLEY DAVIDSON IS RECALLING 11,005 FLSTSB, FXSTSSE2, AND FXSTSSE3 MY 2008 AND 2009 MOTORCYCLES. THE ACORN STUD AT THE BRAKE REACTION LINK MAY FALL OUT DURING USE.

Risk: IF THIS OCCURS, THE FRONT BRAKE AND FENDER ASSEMBLY WOULD NO LONGER BE ADEQUATELY RETAINED. THIS CONDITION COULD LEAD TO A CRASH AND POTENTIAL INJURY TO OR DEATH OF THE RIDER.

Remedy: DEALERS WILL REPLACE THE EXISTING ACORN STUD WITH A NEW ACORN STUD AND RETAINING CLIP. THE RECALL BEGAN ON JUNE 2009. OWNERS MAY CONTACT HARLEY DAVIDSON AT 1-414-343-4056.

Source: NHTSA. View all Harley-Davidson recalls →
