2009Harley-Davidson FXSTC Softail Custom

Rate this bike

42 fields on record

The 2009 Harley-Davidson FXSTC Softail Custom is a classic cruiser designed for riders seeking authentic custom styling with reliable performance. Its 1584cc V-twin engine delivers substantial torque for comfortable highway cruising, while the iconic Softail frame and belt drive provide the timeless Harley character. Best known for its low-slung aesthetic and vintage appeal, this model suits traditional cruiser enthusiasts valuing style and heritage.

Capacity: 1584.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 303.0 kg
Seat height: 672 mm
Power: 75.0 HP (55.2 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2009 Harley-Davidson FXSTC Softail Custom

vs the 2008

Spec	2008	2009
Seat height	719 mm (28.3 inches)	672 mm (26.5 inches)
Front suspension	—	41.3 mm telescopic, chrome dust covers
Rear suspension	—	Hidden, horizontal-mounted, coil-over
Front brakes	Single disc. 4-piston calipers	Single disc. 4-piston
Rear brakes	Single disc. 2-piston torque-free calipers	Single disc. 2-piston

Other years 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding50%

Touring45%

Two-up40%

Track5%

Best for: Built for stylish boulevard cruising and image-driven custom looks rather than outright speed or long-distance touring comfort.
Built for: A laid-back, torque-rich big-twin cruiser that rewards relaxed throttle-rolling rides over aggressive cornering or high-rpm thrills.
Not ideal for: Not a good fit for riders wanting agile cornering, off-road capability, or a sporty, high-speed riding experience.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 672mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2009 Harley-Davidson FXSTC Softail Custom, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1584.0 ccm
Power: 75.0 HP (55.2 kW)
Torque: 117.0 Nm (11.9 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2475 HP/kg (dry)
Bore x stroke: 95.3 x 111.1 mm
Compression: 9.2:1
Cooling system: Air
Fuel system: Injection
Starting: Electric
Valves per cylinder: 2
Lubrication system: Pressurized, dry-sump

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: 9-plate, wet

Dimensions & weight

Wheelbase: 1700 mm
Overall length: 2410 mm
Overall width: 927 mm
Overall height: 1313 mm
Seat height: 672 mm
Dry weight: 303.0 kg
Wet weight: 319.0 kg
Fuel capacity: 18.90 litres
Ground clearance: 130 mm
Oil capacity: 3.10 litres

Chassis & suspension

Frame: Mild steel tubular frame; rectangular section backbone;stamped, cast, and forged junctions; forged fender supports; MIG welded
Front suspension: 41.3 mm telescopic, chrome dust covers
Rear suspension: Hidden, horizontal-mounted, coil-over
Front wheel travel: 142 mm
Rear wheel travel: 109 mm
Rake (fork angle): 32.0°
Trail: 147 mm

Brakes & wheels

Front brakes: Single disc. 4-piston
Front brakes diameter: 292 mm
Rear brakes: Single disc. 2-piston
Rear brakes diameter: 292 mm
Front tyre: MH90-21
Rear tyre: 200/55-R17

Other

Color options: Vivid Black, Dark Blue Pearl, Red Hot Sunglo, Deep Turquoise and Antique White, Flame Blue Pearl and Pewter Pearl
Modifications compared to previous model: New lowprofile front fender

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1999	2002	2005	2007	2009	2010
Capacity	1340 cc	1450 cc	1450 cc	1573 cc	1584 cc	1584 cc
Dry weight	—	—	—	305 kg	303 kg	304 kg
Seat height	—	—	—	719 mm	672 mm	670 mm
Fuel capacity	19.7 L	19.7 L	19.7 L	18.9 L	18.9 L	19.7 L
