Harley-Davidson FLTRSE3 CVO Road Glide - 2009 Specifications and Reviews

2009

General information
Category	Custom / cruiser
Year	2009
Model	Harley-Davidson FLTRSE3 CVO Road Glide
Engine and Transmission Specifications
Clutch	Hydraulically actuated, 9-plate wet, with high performance spring
Transmission typefinal drive	Belt
Gearbox	6-speed
Cooling system	Air
Starter	Electric
Fuel system	Injection
Bore x stroke	101.6 x 111.3 mm (4.0 x 4.4 inches)
Compression	9.2:1
Torque	155.00
Stroke	4
Engine type	V2
Capacity:	1800.00 ccm (109.84 cubic inches)

Physical measures and capacities
Wheelbase	1,614 mm (63.5 inches)
Ground clearance	130 mm (5.1 inches)
Overall length	2,428 mm (95.6 inches)
Seat height	668 mm (26.3 inches) If adjustable, lowest setting.
Dry weight	384.0 kg (846.6 pounds)

Harley-Davidson FLTRSE3 CVO Road Glide dimensions and frame
Exhaust system	Chrome, 2-1-2 exhaust header pipe design with
Rear brakes diameter	300 mm (11.8 inches)
Rear brakes	Single disc. 2-piston calipers
Front brakes diameter	300 mm (11.8 inches)
Front brakes	Double disc. 4-piston calipers
Rear tyre dimensions	180/55-B18
Front tyre dimensions	130/70-B18
Rear suspension travel	51 mm (2.0 inches)
Rear suspension	Air-adjustable
Front suspension travel	117 mm (4.6 inches)
Front suspension	41.3mm telescopic, cartridge-style damping
Trail	170 mm (6.7 inches)
Rake (fork angle)	26.0°
Frame type	New mild steel, single spar rigid backbone with
Speed and acceleration
Color options	Titanium Dust with Ghost Feather graphics; Electric Orange and Vivid Black with Ghost Feather graphics
Fuel capacity	22.70 litres (6.00 gallons)
