Category: | Custom / cruiser |
Year: | 2010 |
Model: | Harley-Davidson XL 883C Sportster 883 Custom |
|
Engine and Transmission Specifications |
Exhaust system: | Chrome, staggered shorty exhaust with dual mufflers |
Clutch: | 9-plate, wet |
Transmission type,final drive: | Belt |
Gearbox: | 5-speed |
Cooling system: | Air |
Lubrication system: | Wet sump |
Fuel system: | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
Bore x stroke: | 76.2 x 96.8 mm (3.0 x 3.8 inches) |
Compression: | 9.0:1 |
Torque: | 70.00 Nm (7.1 kgf-m or 51.6 ft.lbs) @ 3750 |
Engine type: | V2, four-stroke |
Capacity: | 883.00 ccm (53.88 cubic inches) |
Brakes, suspension, Frame and wheels |
Rear brakes diameter: | 292 mm (11.5 inches) |
Rear brakes: | Single disc. Single piston |
Front brakes diameter: | 292 mm (11.5 inches) |
Front brakes: | Single disc. Dual piston |
Rear tyre dimensions: | 150/80-16 |
Front tyre dimensions: | 402/90-21 |
Rear suspension travel: | 54 mm (2.1 inches) |
Rear suspension: | Coil-over shocks, preload dual adjustments |
Front suspension travel: | 145 mm (5.7 inches) |
Front suspension: | Fork 39mm |
Trail: | 120 mm (4.7 inches) |
Rake (fork angle): | 30.0° |
Frame type: | Mild steel tubular frame; circular sections; cast junctions |
|
Physical measures and capacities |
Oil capacity: | 2.50 litres (0.17 quarts) |
Fuel capacity: | 12.50 litres (3.30 gallons) |
Wheelbase: | 1,520 mm (59.8 inches) |
Ground clearance: | 120 mm (4.7 inches) |
Overall length: | 2,275 mm (89.6 inches) |
Seat height: | 715 mm (28.1 inches) If adjustable, lowest setting. |
Dry weight: | 255.0 kg (562.2 pounds) |
Other specs |
Color options: | Vivid Black, Scarlet Red, Brilliant Silver Pearl, Flame Blue Pearl |
