Cruisers
2009Harley-Davidson XL 883R Sportster 883R
39 fields on record
The 2009 Harley-Davidson XL 883R Sportster is an entry-level cruiser that appeals to new riders and commuters seeking an authentic Harley experience. Its 883cc V-twin engine delivers accessible power with classic styling, while the nimble handling and manageable seat height make it ideal for urban riding and highway cruising alike.
- Capacity
- 883.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 251.0 kg
- Seat height
- 714 mm
- Power
- 53.0 HP (39.0 kW)
What’s new for the 2009 Harley-Davidson XL 883R Sportster 883R
vs the 2006| Spec | 2006 | 2009 |
|---|---|---|
| Torque | 69.2 Nm (7.1 kgf-m or 51.0 ft.lbs) | 70.0 Nm (7.1 kgf-m or 51.6 ft.lbs) |
| Dry weight | 254.0 kg (560.0 pounds) | 251.0 kg (553.4 pounds) |
| Front brakes | Double disc | Single disc. Dual piston calipers |
| Rear brakes | Single disc | Single disc. Single piston |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for relaxed street cruising and short rides where style and V-twin character matter more than outright speed.
- Built for
- A classic, low-revving American V-twin cruiser with laid-back attitude, punchy low-end torque, and minimal frills.
- Not ideal for
- Not a good fit for riders wanting sharp cornering performance, long-distance touring comfort, or any off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 883.0 ccm
- Power
- 53.0 HP (39.0 kW)
- Torque
- 70.0 Nm (7.1 kgf-m)
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.2112 HP/kg (dry)
- Bore x stroke
- 76.2 x 96.8 mm
- Compression
- 8.9:1
- Cooling system
- Air
- Fuel system
- Injection
- Starting
- Electric
- Valves per cylinder
- 2
- Lubrication system
- Dry-sump
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Belt
- Clutch
- 9-plate, wet
Dimensions & weight
- Wheelbase
- 1520 mm
- Overall length
- 2245 mm
- Seat height
- 714 mm
- Dry weight
- 251.0 kg
- Wet weight
- 262.6 kg
- Fuel capacity
- 12.50 litres
- Ground clearance
- 141 mm
- Oil capacity
- 2.50 litres
Chassis & suspension
- Frame
- Mild steel tubular frame; circular sections; cast junctions
- Front suspension
- 39mm fork
- Rear suspension
- Coil-over, preload dual-adjustable
- Front wheel travel
- 141 mm
- Rear wheel travel
- 104 mm
- Rake (fork angle)
- 30.0°
- Trail
- 117 mm
Brakes & wheels
- Front brakes
- Single disc. Dual piston calipers
- Front brakes diameter
- 292 mm
- Rear brakes
- Single disc. Single piston
- Rear brakes diameter
- 292 mm
- Front tyre
- 100/90-19
- Rear tyre
- 150/80-16
Other
- Color options
- Vivid Black, Dark Blue Pearl, Mirage Orange Pearl
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2006 | 2009 | 2010 | 2011 |
|---|---|---|---|---|
| Capacity | 883 cc | 883 cc | 883 cc | 883 cc |
| Dry weight | 254 kg | 251 kg | 251 kg | 243 kg |
| Seat height | 714 mm | 714 mm | 760 mm | 760 mm |
| Fuel capacity | 12.5 L | 12.5 L | 12.5 L | 12.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Harley-Davidson XL 883R Sportster 883R?
The 2009 Harley-Davidson XL 883R Sportster 883R has a Capacity of 883.0 ccm (53.88 cubic inches).
What engine power does the Harley-Davidson XL 883R Sportster 883R have?
The 2009 Harley-Davidson XL 883R Sportster 883R has a Power of 53.0 HP (39.0 kW).
How many gears does the Harley-Davidson XL 883R Sportster 883R have?
The 2009 Harley-Davidson XL 883R Sportster 883R has a Gearbox of 5-speed.
What is the torque of the Harley-Davidson XL 883R Sportster 883R?
The 2009 Harley-Davidson XL 883R Sportster 883R has a Torque of 70.0 Nm (7.1 kgf-m or 51.6 ft.lbs).
How much does the Harley-Davidson XL 883R Sportster 883R weigh?
The 2009 Harley-Davidson XL 883R Sportster 883R has a Dry weight of 251.0 kg (553.4 pounds).
