Harley-Davidson XL 883 Sportster 883 - 2009 Specifications and Reviews

2009
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2009
Model:Harley-Davidson XL 883 Sportster 883

Engine and Transmission Specifications

Clutch:9-plate, wet
Transmission typefinal drive:Belt
Gearbox:5-speed
Cooling system:Air
Starter:Electric
Fuel system:Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke:76.2 x 96.8 mm (3.0 x 3.8 inches)
Compression:8.9:1
Torque:70.00
Stroke:4
Engine type:V2
Capacity:883.00 ccm (53.88 cubic inches)


Physical measures and capacities

Wheelbase:1,520 mm (59.8 inches)
Ground clearance:141 mm (5.6 inches)
Overall length:2,260 mm (89.0 inches)
Seat height:693 mm (27.3 inches) If adjustable, lowest setting.
Dry weight:251.0 kg (553.4 pounds)


Harley-Davidson XL 883 Sportster 883 dimensions and frame

Exhaust system:Chrome, staggered shorty exhaust with dual mufflers
Rear brakes diameter:292 mm (11.5 inches)
Rear brakes:Single disc. Single piston
Front brakes diameter:292 mm (11.5 inches)
Front brakes:Single disc. 2-piston calipers
Rear tyre dimensions:150/80-16
Front tyre dimensions:100/90-19
Rear suspension:Coil-over; preload dual-adjustable
Front suspension travel:105 mm (4.1 inches)
Front suspension:39mm fork
Trail:117 mm (4.6 inches)
Rake (fork angle):30.0°
Frame type:Mild steel tubular frame; circular sections; cast junctions

Speed and acceleration

Modifications compared to previous model:New low-profile front fender; New rear shocks for improved ride quality.
Color options:Vivid Black, Flame Blue Pearl
Fuel capacity:12.50 litres (3.30 gallons)
