2019KTM 1090 Adventure

Rate this bike

29 fields on record

The 2019 KTM 1090 Adventure is a mid-weight adventure bike designed for riders seeking genuine off-road capability with street versatility. Known for its agile handling, manageable power delivery, and excellent suspension performance, it excels on mixed terrain and remote routes. Its light weight, tall stance, and quality Brembo braking system make it ideal for exploratory touring and backcountry adventures.

Capacity: 1090.0 ccm
Engine: V-Twin, four-stroke
Gearbox: Not on record
Know it? Add it →
Dry weight: 205.0 kg
Seat height: 850 mm
Power: 123.4 HP (90.1 kW)

⇄ Compare with another bike All model years

What’s new for the 2019 KTM 1090 Adventure

vs the 2018

Spec	2018	2019
Engine capacity	1050.0 ccm (64.07 cubic inches)	1090.0 ccm (66.52 cubic inches)
Power	125.0 HP (91.2 kW)	123.4 HP (90.1 kW)
Gearbox	6-speed	not listed
Front brakes	Double disc. ABS. Four-piston calipers. Radially mounted. Brembo	Double disc. Brembo four-piston radial fixed calliper
Rear brakes	Single disc. ABS. Two-piston calipers. Brembo.	Single disc. Brembo twin-piston fixed calliper, brake disc

Other years 2017 2018 2019

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail75%

Cornering82%

City riding65%

Daily riding70%

Touring85%

Two-up70%

Track55%

Best for: Built as a versatile sport-touring adventure bike that can handle long highway stretches, twisty roads, and moderate off-road excursions with equal competence.
Built for: A muscular, aggressive V2 adventure bike that rewards confident throttle input with strong midrange power and agile handling for its class.
Not ideal for: Not ideal for shorter riders or absolute beginners seeking a light, low, low-maintenance commuter bike.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 850mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with tip-toe one foot on the 2019 KTM 1090 Adventure, with a moderate knee angle of around 90 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1090.0 ccm
Power: 123.4 HP (90.1 kW)
CO2 Emissions: 130 CO2 g/km
Engine type: V-Twin, four-stroke
Fuel consumption: 5.60 litres/100 km (17.9 km/l)
Power/weight ratio: 0.6020 HP/kg (dry)
Bore x stroke: 103.0 x 63.0 mm
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: Digetal
Torque: Not on record - add it

Transmission

Transmission type: Manual
Final drive: Chain
Clutch: PASC slipper clutch, hydraulically actuated

Dimensions & weight

Wheelbase: 1560 mm
Seat height: 850 mm
Dry weight: 205.0 kg
Fuel capacity: 23.00 litres
Ground clearance: 220 mm

Chassis & suspension

Frame: Chromium-Molybdenum steel trellis frame, powder coated
Front suspension: WP upside-down Ø 43 mm
Rear suspension: WP monoshock
Front wheel travel: 185 mm
Rear wheel travel: 190 mm

Brakes & wheels

Front brakes: Double disc. Brembo four-piston radial fixed calliper
Front brakes diameter: 320 mm
Rear brakes: Single disc. Brembo twin-piston fixed calliper, brake disc

Other

Color options: Black/Orange

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2017	2018	2019
Capacity	1050 cc	1050 cc	1090 cc
Dry weight	205 kg	205 kg	205 kg
Seat height	850 mm	850 mm	850 mm
Fuel capacity	23 L	23 L	23 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Rider Reviews

—

☆☆☆☆☆

Be the first to rate

MotorcycleDB Review

The 2019 KTM 1090 Adventure is a impressive and versatile adventure motorcycle that offers powerful performance and excellent handling. With a 1,050cc V-twin engine, this bike delivers plenty of torque and acceleration, making it capable of tackling a wide range of riding conditions. Whether you're cruising on the highway or navigating off-road trails, the 1090 Adventure provides a smooth and controlled riding experience. Additionally, it comes equipped with advanced features such as traction control, ABS, and a slipper clutch, enhancing its overall safety and performance.

One of the standout features of the 2019 KTM 1090 Adventure is its adjustable suspension, allowing riders to customize their ride for optimal comfort and handling. The bike also boasts a comfortable seating position and a spacious tank for longer rides. Overall, the 1090 Adventure offers a well-rounded package for riders who want a capable and reliable adventure motorcycle that can handle a variety of terrains. Its combination of power, agility, and advanced technology make it a top choice for riders looking for a versatile and capable adventure bike.
