Adventure Motorcycles

2016KTM 1190 Adventure

★ 5.0

34 fields on record

The 2016 KTM 1190 Adventure is a high-performance adventure motorcycle designed for experienced riders seeking serious off-road capability combined with road-going comfort. Known for its lightweight construction, advanced electronics including ride-by-wire and traction control, and impressive ground clearance, it excels in mixed terrain exploration. The bike's adjustable seat height and manageable weight make it accessible to taller riders while maintaining genuine adventure credentials.

Capacity: 1195.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 212.0 kg
Seat height: 860 mm
Power: 150.0 HP (109.5 kW)

⇄ Compare with another bike ＋ Add to garage All model years ⚠ Recalls listed (1)

What’s new for the 2016 KTM 1190 Adventure

vs the 2015

Spec	2015	2016
Front suspension	WP Suspension Up Side Down	WP-EDS USD Ø 48 mm
Rear suspension	WP Suspension monoshock	WP-EDS Monoshock

Other years 2013 2014 2015 2016

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail72%

Cornering82%

City riding60%

Daily riding68%

Touring88%

Two-up75%

Track55%

Best for: Built as a versatile long-distance adventure tourer, it excels at devouring highway miles and tackling light-to-moderate off-road terrain with equal confidence.
Built for: It has the character of a muscular, torque-rich V-twin adventure bike that rewards confident, assertive riding on open roads and gravel alike.
Not ideal for: It is not the ideal choice for a beginner rider or someone seeking a lightweight, nimble machine for tight city commuting.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 860mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with tip-toe one foot on the 2016 KTM 1190 Adventure, with a moderate knee angle of around 95 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1195.0 ccm
Power: 150.0 HP (109.5 kW)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.7075 HP/kg (dry)
Bore x stroke: 105.0 x 69.0 mm
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: Keihin EMS with RBW, twin ignition
Lubrication system: Forced oil lubrication with 3 rotor pumps
Torque: Not on record - add it

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: PASC slipper clutch, hydraulically actuated

Dimensions & weight

Wheelbase: 1560 mm
Seat height: 860 mm
Dry weight: 212.0 kg
Wet weight: 230.0 kg
Fuel capacity: 23.00 litres
Ground clearance: 220 mm

Chassis & suspension

Frame: Chromium-Molybdenum steel trellis frame, powder coated
Front suspension: WP-EDS USD Ø 48 mm
Rear suspension: WP-EDS Monoshock
Front wheel travel: 190 mm
Rear wheel travel: 190 mm
Rake (fork angle): 26.0°

Brakes & wheels

Front brakes: Double disc. ABS. Four-piston calipers. Radially mounted.
Front brakes diameter: 320 mm
Rear brakes: Single disc. ABS. Two-piston calipers.
Rear brakes diameter: 267 mm
ABS: Yes

Other

Color options: Grey, Orange
Comments: Windscreen. Ride-by-wire system. Traction Control. Disengageable ABS.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2013	2014	2015	2016
Capacity	1195 cc	1195 cc	1195 cc	1195 cc
Dry weight	212 kg	212 kg	212 kg	212 kg
Seat height	860 mm	860 mm	860 mm	860 mm
Fuel capacity	23 L	23 L	23 L	23 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 1 recall may apply

SERVICE BRAKES, HYDRAULIC:FOUNDATION COMPONENTS:HOSES, LINES/PIPING, AND FITTINGSNov 2016 · 16V854000

KTM North America, Inc. (KTM) is recalling certain model year 2015-2016 1290 Super Adventure motorcycles manufactured December 1, 2014, to March 10, 2016, and 2013-2016 1190 Adventure and Adventure R motorcycles manufactured November 20, 2012, to April 25, 2016. In the affected vehicles, the wiring harness can fray and contact the ABS modulator. If the brake line is electrically conductive, the brake line may overheat and melt.

Risk: If the brake line melts, brake failure may result, increasing the risk of a crash.

Remedy: KTM will notify owners, and dealers will re-position the wiring harness for the electronic control unit, free of charge. The manufacturer has not yet provided a notification schedule. Owners may contact KTM customer service at 1-888-985-6090.

These recalls cover some 2016 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.

Source: NHTSA. View all KTM recalls →
