Category: | Super motard |
Year: | 2011 |
Model: | Kawasaki KLR 650 |
|
Engine and Transmission Specifications |
Transmission type,final drive: | Chain |
Gearbox: | 5-speed |
Cooling system: | Liquid |
Ignition: | Electric CDI |
Fuel control: | DOHC |
Fuel system: | Carburettor. Keihin CVK40 |
Valves per cylinder: | 4 |
Bore x stroke: | 100.0 x 83.0 mm (3.9 x 3.3 inches) |
Compression: | 9.8:1 |
Engine type: | Single cylinder, four-stroke |
Capacity: | 651.00 ccm (39.72 cubic inches) |
Brakes, suspension, Frame and wheels |
Front brakes diameter: | 280 mm (11.0 inches) |
Front brakes: | Single disc |
Rear tyre dimensions: | 130/80-17 |
Front tyre dimensions: | 90/90-21 |
Rear suspension: | Uni-Trak single-shock system with 5-way preload and stepless rebound damping / 7.3 in. |
Front suspension: | 41mm telescopic fork / 7.9 in. |
Trail: | 112 mm (4.4 inches) |
Rake (fork angle): | 28.0° |
Frame type: | Semi-double cradle, high-tensile steel |
|
Physical measures and capacities |
Fuel capacity: | 21.95 litres (5.80 gallons) |
Wheelbase: | 1,481 mm (58.3 inches) |
Ground clearance: | 211 mm (8.3 inches) |
Overall width: | 960 mm (37.8 inches) |
Overall length: | 2,296 mm (90.4 inches) |
Overall height: | 1,349 mm (53.1 inches) |
Seat height: | 889 mm (35.0 inches) If adjustable, lowest setting. |
Weight incl. oil, gas, etc: | 196.0 kg (432.0 pounds) |
Other specs |
Wheelbase: | 965 mm (38.0 inches) |
Rear brakes diameter: | 200 mm (7.9 inches) |
Rear brakes: | Single disc |
Rear tyre: | 18/9-8 |
Front tyre: | 18/7-8 |
Rear Suspension: | Swingarm with single shock absorber / 2.9 in. |
Front Suspension: | Single A-arm with twin shock absorbers / 2.8 in. |
Bore x Stroke: | 47.0 x 51.8 mm (1.9 x 2.0 inches) |
Compression: | 10.0:1 |
Model: | Kawasaki KFX 90 |
Color options: | Metallic Flat Raw Graystone/Ebony, Candy Plasma Blue/Galaxy Silver, Candy Burnt Orange/Galaxy Silver |
Factory warranty: | 12 Months |
Starter: | Electric |
