Kawasaki KLR 650 - 2011 Specifications and Reviews
General information | |
| Category: | Super motard |
| Year: | 2011 |
| Model: | Kawasaki KLR 650 |
Engine and Transmission Specifications | |
| Transmission type,final drive: | Chain |
| Gearbox: | 5-speed |
| Cooling system: | Liquid |
| Ignition: | Electric CDI |
| Fuel control: | DOHC |
| Fuel system: | Carburettor. Keihin CVK40 |
| Valves per cylinder: | 4 |
| Bore x stroke: | 100.0 x 83.0 mm (3.9 x 3.3 inches) |
| Compression: | 9.8:1 |
| Engine type: | Single cylinder, four-stroke |
| Capacity: | 651.00 ccm (39.72 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Front brakes diameter: | 280 mm (11.0 inches) |
| Front brakes: | Single disc |
| Rear tyre dimensions: | 130/80-17 |
| Front tyre dimensions: | 90/90-21 |
| Rear suspension: | Uni-Trak single-shock system with 5-way preload and stepless rebound damping / 7.3 in. |
| Front suspension: | 41mm telescopic fork / 7.9 in. |
| Trail: | 112 mm (4.4 inches) |
| Rake (fork angle): | 28.0° |
| Frame type: | Semi-double cradle, high-tensile steel |
Physical measures and capacities | |
| Fuel capacity: | 21.95 litres (5.80 gallons) |
| Wheelbase: | 1,481 mm (58.3 inches) |
| Ground clearance: | 211 mm (8.3 inches) |
| Overall width: | 960 mm (37.8 inches) |
| Overall length: | 2,296 mm (90.4 inches) |
| Overall height: | 1,349 mm (53.1 inches) |
| Seat height: | 889 mm (35.0 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc: | 196.0 kg (432.0 pounds) |
Other specs | |
| Wheelbase: | 965 mm (38.0 inches) |
| Rear brakes diameter: | 200 mm (7.9 inches) |
| Rear brakes: | Single disc |
| Rear tyre: | 18/9-8 |
| Front tyre: | 18/7-8 |
| Rear Suspension: | Swingarm with single shock absorber / 2.9 in. |
| Front Suspension: | Single A-arm with twin shock absorbers / 2.8 in. |
| Bore x Stroke: | 47.0 x 51.8 mm (1.9 x 2.0 inches) |
| Compression: | 10.0:1 |
| Model: | Kawasaki KFX 90 |
| Color options: | Metallic Flat Raw Graystone/Ebony, Candy Plasma Blue/Galaxy Silver, Candy Burnt Orange/Galaxy Silver |
| Factory warranty: | 12 Months |
| Starter: | Electric |
